Inconel Alloy Mesh,a high-performance chromium-iron-nickel based alloy mesh manufactured through precision weaving and vacuum sintering processes. We focus on the R&D and production of Inconel Alloy Mesh, providing cost-effective solutions for global industries with advanced production technology, strict quality control and flexible customization capabilities. It is the preferred material for high-temperature, corrosive and harsh working conditions such as aerospace, chemical engineering and heat treatment.
Core Advantages of Inconel Alloy Mesh
Excellent High-Temperature Performance: As a chromium-iron-nickel based alloy, Inconel Alloy Mesh features outstanding high-temperature oxidation resistance. It can maintain structural stability and mechanical properties even after repeated heating and cooling cycles without embrittlement, and its high-temperature performance can be further enhanced through heat treatment. It can operate stably at high temperatures up to 1200℃ (depending on the alloy grade).
Superior Corrosion Resistance: Inconel Alloy Mesh exhibits excellent corrosion resistance in harsh environments such as acid, alkali, high-temperature gas and seawater, effectively resisting corrosion from HCl, SO₂ and other corrosive media, and is not prone to pitting or stress corrosion, ensuring long-term stable operation in harsh working conditions.
Flexible Customization & Strong Adaptability: Common grades include Inconel 600, 601, 625, 800 and 825. Mesh size, wire diameter, width, length and surface treatment can be customized according to customer needs, which can be directly used without additional processing, adapting to various industrial application scenarios.
Widely Applicable: Inconel Alloy Mesh is widely used in aerospace, chemical engineering, heat treatment, nuclear industry, petroleum refining and other fields, such as high-temperature furnace mesh belts, catalyst support grids, exhaust system components and high-temperature gas filtration components.
-
High Cost-Effectiveness & Durability: Adopting precision weaving and vacuum sintering processes, the mesh structure is firm and wear-resistant, with a long service life and low maintenance cost. It is an ideal choice for import substitution, providing high-quality and cost-effective solutions for customers.
Product Specifications | Inconel Alloy Mesh Data Sheet
Parameter Name |
Standard Specification |
Customizable Range |
Remarks |
Alloy Grade |
Inconel 600, 601, 625 |
Inconel 800, 825, etc. |
Meets ASTM B164/B564 standards |
Wire Diameter |
0.1-0.5mm |
0.08-1.0mm |
Uniform wire diameter, no burrs or breakage |
Mesh Size |
10-200 mesh |
5-400 mesh |
Uniform mesh, stable structure |
Width |
0.5-2.0m |
0.3-3.0m |
Smooth surface, no obvious unevenness |
Length |
10-50m (roll) |
Customizable |
Sheet or roll type available |
Color |
Metallic Silver |
Customizable (surface treatment) |
No obvious color difference, anti-oxidation treatment available |
Operating Temperature |
≤800℃ |
≤1200℃ (depending on grade) |
Stable structure at high temperature, no deformation |
Operating Pressure |
≤3MPa |
Adjustable on demand |
Strong pressure resistance, not easy to deform |
Corrosion Resistance |
Excellent |
Reinforceable surface treatment |
Resistant to acid, alkali, high-temperature gas and seawater corrosion |
Production Process |
Precision Weaving → Mesh Cleaning → Lamination → Vacuum Sintering |
Optimizable on demand |
Advanced core process, stable product performance |
