Saflow Ladle Refractory Slide Gate Plate for Steel Mill
Product Description
Simple production introduction
SNREF Slide Gate Plate adopts High quality bauxite material , also takes tabular alumina, carbonaceous material and zirconia-containing material as main raw materials, adds in high performance antioxidants, uses phenolic resin as binder, formed under high-pressure and burned under high temperature. The slide plates have the advantages of high strength, good erosion resistance, thermal shock resistance and good stability etc., mainly used in large and medium-sized ladle.
1) C series Small size Slide Plate---mainly for Indonesia, Vietnam, Myanmar, Thailand, for 5-20 tons ladles.
2) QC series Slide Plate mainly for India, Turkey,Middle East, Indonesia, Pakistan, Italy , mainly for 20-30 tons ladles.
3) B250 , safllow, HB250, Mainly for Pakistan, Middle East market.
4) Flocon sereis Slide Plate mainly for Turkey, Middle East, Italy, Braizl, and soon.
5) CS Serise Slide Plate mainly for Europe countries. mostly for larges ladles such as more than 120 tons.
Type of production design
1) High Temperature Burnt Slide Gate Plate and ladle nozzle system
High performance ladle slide gate plate refractories adopts tabular alumina,carbonaceous material and zirconia-containing material as main raw materials, adds in high performance antioxidants, uses phenolic resin as binder, formed under high-pressure and burned under high temperature. Mainly used in large and medium-sized ladles.
2) Low Temperature Burnt Slide Gate Plate and nozzle system
Tabular alumina, zirconia-containing material and spinel as major raw materials, adding in special metal, using phenolic resin as binder, being burned under low temperature to produce the products, Mainly used in small and medium-sized ladle.
3) Un-burned Slide Gate Plate and nozzle system
Without the process of burned, tar impregnated and distilled, simple processing. Mainly used in small and medium-sized ladle.
Detailed Photos
Product Parameters
| Chemical and Physical Properties | Ladle Slide Gate Plate (General) | ||
| Magnesia material | Al-C | Al- Zr-C | |
| apparent porosity % max | 10 | 8 | 8 |
| Bulk Density g/cm3 min | 3.0 | 3.05 | 3.1 |
| Compressive strength MPa min | 120 | 120 | 120 |
| Al2O3 % min | 8 | 85 | 85 |
| ZrO2 % min | 4 | ||
| C % min | 3 | 3 | 3 |
| MgO % | 65 min | ||
| Service Life heats | 1-2 | 1-3 | 1-5 |
Packaging & Shipping
Service Result for slide gate plate and nozzle system:
Service life depends on many points:
1)Different Raw Material,
2)Production Process(Firing temperature, oil immersion, drying temperature...)
3)Steel type
4)Steel making condition
5)Different operation mode
And so on....
Our Advantages
S1 Saflow Ladle Refractory Slide Gate Plate for Steel Mill
The slide plates have the advantages of high strength, good erosion resistance, thermal shock resistance and good stability etc.,mainly used in large and medium-sized ladle.
Company Profile
Shandong Sinorefractory New Materials Co.,Ltd (SinoRefractory)has been focusing on international marketing of flow control refractories in iron and steel industry for 17 years.
SinoRefractory is the second generation of refractories export enterprise developed out of EMEI Group.Supported by one of China's largest production bases in functional refractory materials.
Through years of development in the field of exporting top quality refractories to worldwide markets,SinoRefractory aims at researching,producing,marketing and exporting high standard Ladle slide gate plate,Ladle Nozzles,Well blocks,Purging plugs,Nozzle stuffing sand,Refractory castables, Slide gate Mechanisms etc.
Up to now,SinoRefractory has supplied high quality refractory products and services to nearly 70 top-hundred global steel enterprises.
SinoRefractory will always put clients'interest in the first place,striving to provide a wide range of services,including technical solution,pre-sales support,after-sales services,installation team support,professional know-how according to the changing of steelmaking condition,etc.
We are not only selling products,we are more focused on supporting,developing and growing together with clients.
