CS80 Anti-Clogging Slide Gate Nozzle Technology for Clean Steel Production
Product Description
Slide Gate Plate has various range of formulas including Alumina Carbon,Alumina Zirconia Carbon,Magnesia Spinel and so on to suit different steelmaking conditions to achive best service life.
SNREF Slide Gate Plate adopts High quality bauxite material , also takes tabular alumina, carbonaceous material and zirconia-containing material as main raw materials, adds in high performance antioxidants, uses phenolic resin as binder, formed under high-pressure and burned under high temperature.
The slide plates have the advantages of high strength, good erosion resistance, thermal shock resistance and good stability etc., mainly used in large and medium-sized ladle.
Slide gate plate brick is becoming more and more important in modern iron and steel smelting process, and becoming an indispensable part of smelting.
It is a molten steel control device of continuous casting machine in the process of casting.
It could precisely adjust the molten steel flow rate that from ladle to continuous casting tundish to balance the inflows and outflows of molten steel, which makes it easier to control the continuous casting operation.now, slide nozzle system is widely used in ladle and tundish ladle in worldwide.
Feature of SNREF slide gate plate, nozzle and well block:
1.Excellent thermal stability
2.High temperature strength
3.Resistance to molten metal and slag
4.Consistency in shape and size
5.Ability to sustain mechanical treatment without detriment to the surface integrity
Detailed Photos
Deep Burnt Ladle Flow Control CS80 Alumina Zirconia Carbon Ladle Slide Gate Plate for steelmaking
Adopting tabular corundum, fused alumina, fused alumina zirconia, zirconium mullite as raw materials, through the addition of moderate micro and fine metal powder, by reaction under high temperature, to increase the high temperature performance of plates. Through the adding of moderate boron carbide powder to increase the oxidation resistance of plates. The bonding agent is phenolic resin with high solid content and high carbon residue.
After forming, adopting advanced heating treatment technology, through impregnating, burning to form high performance slide plates. With features of good thermal stability, excellent erosion resistance, stable consistency in shape and size, mainly suitable for ladles over 180 tons or converter slagging slide gate systems.
CS80 Slide Gate Plate Nozzles:
Special Design with Zirconia Insert Plate:
Drawings
CS80 Slide Gate Plate for your reference, will do the customization according to your drawings, steel making condition etc.
Product Parameters
| Al-C Material | ||||
| Al2O3(≥%) | C(≥%) | A.P.P(≤%) | B.D(≥g/cm3) | C.C.S( Mpa) |
| 90 | 3 | 9 | 3.0 | 120 |
| Al-Zr-C Material | |||||
| Al2O3(≥%) | ZrO2(≥%) | C(≥%) | A.P.P(≤%) | B.D(≥g/cm3) | C.C.S(≥Mpa) |
| 85 | 5 | 3 | 8 | 3.1 | 120 |
Packaging & Shipping
Company Profile
Shandong Sinorefractory New Materials Co.,Ltd (SinoRefractory)has been focusing on international marketing of flow control refractories in iron and steel industry for 17 years.
SinoRefractory is the second generation of refractories export enterprise developed out of EMEI Group.Supported by one of China's largest production bases in functional refractory materials.
Through years of development in the field of exporting top quality refractories to worldwide markets,SinoRefractory aims at researching,producing,marketing and exporting high standard Ladle slide gate plate,Ladle Nozzles,Well blocks,Purging plugs,Nozzle stuffing sand,Refractory castables, Slide gate Mechanisms etc.
Up to now,SinoRefractory has supplied high quality refractory products and services to nearly 70 top-hundred global steel enterprises.
SinoRefractory will always put clients'interest in the first place,striving to provide a wide range of services,including technical solution,pre-sales support,after-sales services,installation team support,professional know-how according to the changing of steelmaking condition,etc.
We are not only selling products,we are more focused on supporting,developing and growing together with clients.
Application
Service Result for SNREF Deep Burnt Ladle Flow Control CS60 CS80 Slide Gate Plate for Steel Making:
4-7 heats according to different material and production process
Also service result of slide gate plate depends on so many condition of steel plants. the above is just for your reference.
FAQ
Below are some FAQ and answers about ladle and tundish flow control refractories:
Q: What are the requirements for refractories for ladle?
A: The requirements of refractories for ladle mainly include:
* high temperature resistance
* thermal shock resistance
* resistance to the erosion of the slag
* high temperature with sufficient mechanical strength
* the lining has a certain degree of expansion
Q:What are the reasons for the destruction of refractories for ladle?
A: The main causes of damage are as follows:
When the ladle transports high-temperature molten steel, the high-temperature molten steel and slag at about 1680ºC scour and erode it, especially in the slag line part, the scouring and erosion is more serious, and it is an important factor to decide the service life of the ladle.
LF and other extra-oven refining treatment on the unburnt brick damage is serious.
Q:What steel grades are different materials of slide plate bricks suitable for respectively?
A: Different materials of slide plate bricks are applicable to different steel grades. For example,
Al2O3-ZrO2-C slide gate plate can be used as ladle sliding gate plate due to its excellent erosion resistance and thermal shock stability, which can adapt to the casting of various steel grades, and ther are the following materilas based on customer's steel making condition: the MgO-C, MgO-Al-C, MgO-Al-C, MgO-Al-C, MgO-Al-C, MgO-Al-C, MgO-Al-C, MgO-Al-C, MgO-Al-C, and so on.
Q 1:How can I receive best materials or products for my application ?
A: Please send drawing and steelmaking condition to us for evaluation.
Our technical team will recommend suitable formula and workmanship,
our sales team will offer most competitive prices accordingly.
Our "Technical+Sales" team will work on to provide optimum product recommendation for clients.
Q 2:Is the recommended life time guaranteed by SNREF ?
A: Taking into comprehensive consideration base on steelmaking situation and SNREF's product experience, we'll
offer recommended life time of products.
However SNREF doesn't guarantee the life time.
For first time cooperation, SNREF recommends a trial order for testing.
Trial order offers us chance to adjust formula base on actual performance.
SNREF will offer best technical support and expedited delivery for trial order.
Q 3:Can SNREF's refractories work well for my system from other brands?
A: With years of experience in exporting. SNREF has successfully provided refractory materials to a wide range of overseas markets including Asia, North Amercia, South America, Middle East, CIS area etc.
We are experienced with various types of systems.
SNREF is capable to offer consistent and high performance refractory materials to clients worldwide.
For more details, feel free to send inquiry to us.
