AWZ3200001 TXC Active Crystal Oscillator is a vehicle-grade 32.768kHz active crystal oscillator developed and produced by TXC Corporation. It belongs to the vehicle quartz oscillator product line of the TXC AWZ series. Its core positioning is to provide high-precision and high-stability clock signal solutions for the vehicle electronics field, and it is compatible with the strict working environment requirements of vehicle electronic devices. It is the core clock component for devices such as vehicle RTC, vehicle diagnostic (OBD), and vehicle central control.
Core parameters of AWZ3200001 TXC Active Crystal Oscillator: The nominal frequency is 32.768kHz, and the package size is 2.5x2.0mm. The miniaturized design is suitable for the compact layout of vehicle devices; the output type is CMOS, supporting the tri-state output function (Enable), which can be flexibly adapted to different circuit control requirements; the frequency stability reaches ±25ppm (-40~85℃), and the wide temperature working range covers -40~125℃, fully meeting the temperature fluctuation requirements of the vehicle environment. At the same time, multiple stability options such as ±30ppm and ±50ppm are available to adapt to vehicle scenarios with different precision requirements.
Power supply parameters of AWZ3200001 TXC Active Crystal Oscillator: It supports multi-voltage adaptation, and the power supply voltage covers 1.8V, 2.5V, 2.8V, and 3.3V. It is also compatible with the wide voltage ranges of 1.62~3.3V and 2.25~3.63V. With a low-power design, the operating current is controllable, which is suitable for the low-power operation requirements of vehicle devices. It does not require an additional complex power supply circuit and can be directly integrated into the vehicle electronic system.
Product features of AWZ3200001 TXC Active Crystal Oscillator: It uses the mature quartz oscillator manufacturing process of TXC Corporation. By integrating the crystal resonator and the oscillation circuit, it can work stably without an external additional oscillation circuit, simplifying the device integration process; it has excellent anti-interference ability, is suitable for the complex electromagnetic environment of vehicles, with stable signal transmission, low phase noise, and can effectively avoid clock signal distortion; it meets the AEC-Q100 reliability test standard, with vehicle-grade quality, excellent anti-vibration and anti-shock performance, long service life, and low aging rate, ensuring the long-term stable operation of vehicle devices.
Application scenarios of AWZ3200001 TXC Active Crystal Oscillator: It is mainly used in the vehicle electronics field, including vehicle RTC real-time clock modules, vehicle central control systems, vehicle navigation devices, vehicle diagnostic instruments (OBD), vehicle Bluetooth devices, vehicle audio systems, etc.; at the same time, it can be compatible with scenarios such as industrial control and portable electronic devices, providing stable support for various devices that require a high-precision 32.768kHz clock signal. It can directly replace vehicle-grade 32.768kHz active crystal oscillators of the same specification, with strong versatility.
Basic information of AWZ3200001 TXC Active Crystal Oscillator: Brand TXC (TXC Corporation), Model AWZ3200001, Product type Active Crystal Oscillator (XO), Series AWZ series, Purpose Clock signal generation, Package type SMD surface mount, Product grade Vehicle grade, Origin Taiwan, China/Ningbo, Complies with RoHS environmental protection standards, Specification query and bulk supply support are available, suitable for the mass production requirements of vehicle electronics.
