General Electric IS201TBCIH2C Group isolation coating version
The IS201TBCIH2C is a 24-channel coated group-isolated dry contact input terminal board (TBCI = Terminal Board Group Isolation Contact Input, H2C = Group Isolation Coated Version) for the GE Mark Vie Speedtronic platform. The 24 dry contacts are divided into 3 groups of 8 channels/groups with 3 isolation levels. It is compatible with the coated I/O module IS221PDIAH1B and is suitable for group-isolated discrete signal acquisition scenarios in harsh environments such as dust and humidity, and in TMR redundant systems.
Core Hardware and Interfaces
Terminals and Connections: 24 dry contact inputs, divided into 3 isolated groups of 8 inputs/groups, each group with 1 common terminal; barrier-style terminal block; 3 DC-37 pin connectors (JR1/JS1/JT1, corresponding to the R/S/T channels of TMR); 1 3-position power female connector for excitation power/common terminal; 1 37-pin female D-type connector for direct connection to the VTCC/VCRC I/O processor board.
Signals and Protection: Excitation voltage 24 VDC (wide range 16–32 VDC), 1 common terminal per group; 2.5 mA current limit per input; 4 ms hardware filtering + TVS surge protection + PTC resettable fuse, protection against contact bounce, EMI, and overvoltage reverse connection.
Coating and Protection: PCB conformal coating, suitable for harsh environments such as humidity, dust, and chemical corrosion; metal casing for natural heat dissipation, fanless; built-in ID identification, allowing the module to automatically recognize its model.
System Compatibility: Compatible with Mark VIe Speedtronic coated systems; compatible with IS221PDIAH1B coated I/O modules; supports single-mode (single connector) and TMR (three connector) deployments.
Email: xmxblynn@163.com
Phone: +86 18059884797
Parameters Values
Model: IS201TBCIH2C (TBCI 24-channel isolated contact input terminal block, coated version)
Compatible System: Mark VIe Speedtronic Coated System
Number of Inputs: 24 dry contact inputs, 8 channels/group, 3 groups of isolation
Magnetic Voltage: 24 VDC (16–32 VDC)
Hardware Filtering: 4 ms/channel
Power Consumption: Approx. 12 W
Operating Temperature: -40°C to +70°C; Storage: -40°C to +85°C
Certifications: Class 1 Div 2, ATEX, CE, UL; G3 compliant
Mounting Method: Standard DIN rail
Isolation Capacity: 3 groups of isolation, 8 channels per group sharing a common terminal
Safety and Redundancy Features
Coating Protection: PCB conformal coating, suitable for hazardous areas and harsh environments (humidity, dust, chemical corrosion), improving module reliability under harsh industrial conditions.
TMR Compatibility: Three 37-pin connectors correspond to the TMR's R/S/T channels, meeting the SIL 3 redundancy requirements for turbine control and ensuring independent acquisition and fault isolation for the R/S/T channels.
Diagnostic Capabilities: Supports excitation loss and input no-response diagnostics; LEDs indicate power supply, link, and input status, which can be read via ControlST software.
Hazardous Area Compatibility: Class 1 Div 2/ATEX certified, suitable for use in hazardous area control cabinets, compatible with SIS auxiliary system signal acquisition.
