General Electric IS200STCIS1A Single-Point Isolation Contact
The IS200STCIS1A is a 24-channel single-point isolated dry contact input terminal board (STCI = Terminal Board Single-Point Isolation Contact Input, S1A = Standard Protected Version) for the GE Mark VIeS safety platform. It is compatible with safety discrete I/O modules such as the IS220YDIAS1A, and is used for 24-channel single-point isolated dry contact signal acquisition in SIL 3 safety systems, meeting the requirements for TMR redundancy and hazardous area safety signal acquisition.
Core Hardware and Interfaces
Terminals and Connections: 24-channel dry contact input, single-point isolation (each channel has an independent common terminal); barrier-style terminal block; 3 DC-37 pin connectors (JR1/JS1/JT1, corresponding to the TMR R/S/T channels); 1 3-position power female connector for excitation power/common terminal; 1 37-pin female D-type connector for direct connection to the VTCC/VCRC I/O processor board.
Signal and Protection: Excitation voltage 24 VDC (16–32 VDC), independent common terminal for each channel; current limit of 2.5 mA per channel; 4 ms hardware filtering + TVS surge protection + PTC resettable fuse, resistant to contact bounce, EMI, and overvoltage reverse connection.
Protection and Identification: Standard protective coating, suitable for harsh environments such as dust and humidity; metal casing for natural heat dissipation, fanless; built-in ID identification, the module can automatically identify the model.
System Compatibility: Compatible with Mark VIeS safety systems; compatible with safety discrete I/O modules such as IS220YDIAS1A; supports single-mode (single connector) and TMR (three connector) deployments.
Email: xmxblynn@163.com
Phone: +86 18059884797
Parameters Values
Model: IS200STCIS1A (STCI 24-channel single-point isolated contact input terminal block)
Compatible Systems: Mark VIeS Safety Systems
Number of Inputs: 24 dry contact inputs, single-point isolated (each with an independent common terminal)
Magnetic Voltage: 24 VDC (16–32 VDC)
Hardware Filtering: 4 ms/channel
Power Consumption: Approx. 12 W
Operating Temperature: -40°C to +70°C; Storage: -40°C to +85°C
Certifications: Class 1 Div 2, ATEX, CE, UL; SIL 3 compliant
Mounting Method: Standard DIN rail
Isolation Capability: Single-point isolated, each with an independent common terminal
Safety and Redundancy Features
Safety Compliance: Meets SIL 3 safety integrity level, compatible with Mark VIeS safety discrete I/O modules for signal acquisition in safety-related systems.
TMR Compatibility: Three 37-pin connectors correspond to the TMR's R/S/T channels, ensuring independent acquisition and fault isolation for the R/S/T channels, improving system redundancy.
Diagnostic Capabilities: Supports excitation loss and input non-response diagnostics; LEDs indicate power, link, and input status, which can be read via ControlST software.
Hazardous Area Compatibility: Class 1 Div 2/ATEX certified, suitable for use in hazardous area control cabinets, compatible with SIS safety instrumented system signal acquisition.
