Help CenterCustom Sized 4J36 Invar Alloy Plate With Low Thermal Expansion Iron Nickel Alloy Plate for Precision Engineering Applications
Related Products
-
Industrial Grade Iron Nickel Alloy Plate for Cryogenic and High-Temperature EnvironmentsNegotiableMOQ: 50 Kilograms -
Precision-Ground Iron-Nickel Alloy Plates With Technical Support and Delivery GuaranteeNegotiableMOQ: 1 Ton
-
Low Thermal Expansion Iron-Nickel Alloy Plate 4J36/4J32A for Aerospace Precision PartsNegotiableMOQ: 1 Ton
-
High-Temp Resistant Alloy Sheet 4J78 Iron-Nickel Alloy Plate With Excellent Corrosion ResistanceNegotiableMOQ: 1 Ton
-
Industrial Grade Iron Nickel Alloy Plate 4J36 Compatible With Scientific Instruments and ToolsNegotiableMOQ: 50 Kilograms
Experience unparalleled dimensional stability with our custom-sized 4J36 Invar alloy plates, engineered specifically for precision applications where thermal expansion control is critical. Manufactured by Jiangsu Zhonggongte Metallurgical Technology, these plates deliver exceptional performance in environments with temperature fluctuations. With ISO9001 certified quality and global export capabilities, we provide tailored solutions for aerospace, optical systems, and scientific instrumentation industries.
Our 4J36 alloy plates maintain dimensional integrity across temperature variations, significantly reducing calibration drift in sensitive equipment. The customizable sizing allows perfect integration into your existing designs without compromise.
Core Technical Advantages:
Ultra-low thermal expansion - maintains dimensional stability between -250°C to +200°C
Excellent mechanical properties with tensile strength of 440-590 MPa
Superior corrosion resistance in various environments
Controlled magnetic permeability for sensitive applications
Standard Physical Properties:
| Property | Value | Unit |
|---|---|---|
| Density | 8.1 | g/cm³ |
| Melting Point | 1430 | °C |
| Thermal Conductivity | 10 | W/(m·K) |
| Specific Heat Capacity | 515 | J/(kg·K) |
Available thicknesses range from 0.5mm to 150mm with customized length/width configurations. Special surface treatments including polishing and passivation are available upon request. All plates undergo rigorous dimensional verification and non-destructive testing to ensure compliance with precision engineering requirements.
Industry Applications Include:
Laser and optical alignment systems
Satellite and aerospace components
Precision measurement devices
Semiconductor manufacturing equipment
Scientific instrument frameworks
Mold bases for composite materials
With direct manufacturing capabilities and established export channels through Shanghai and Tianjin ports, we ensure reliable global delivery. Our technical team provides comprehensive material selection guidance and application engineering support throughout your project lifecycle.
Frequently Asked Questions:
Q: What tolerances can be achieved for custom-sized plates?
A: Standard dimensional tolerances adhere to ASTM B388 specifications. Precision grinding can achieve ±0.025mm tolerances for critical applications.
Q: Can you provide material certification documentation?
A: Yes, we supply full material traceability with mill test reports including chemical composition and mechanical property verification.
Q: What is the typical lead time for custom orders?
A: Standard sizes ship within 2-3 weeks. Custom dimensions require 4-6 weeks depending on complexity and quantity.
Q: How does 4J36 compare to other low-expansion alloys?
A: 4J36 offers superior thermal stability at room temperatures compared to alternatives like Kovar or Super Invar, with better machinability.
Q: What packaging is used for international shipments?
A: We use weather-resistant wooden crates with anti-corrosion VCI paper and edge protection to ensure damage-free transit.
Leverage our metallurgical expertise for your most demanding precision engineering challenges. Contact our technical sales team today with your project specifications to discuss custom solutions and request material samples. With established operations across five continents and dedicated export support, we deliver reliable performance where dimensional stability matters most.
