1. Basic Information
Standard Number: GB/T 2029-2008
Standard Status: Current
English Name: Cast steel suction valve for seaward sluice
Issuing Department: China State Shipbuilding Corporation
Issuing Date: August 4th, 2008
Implementation Date: February 1st, 2009
Replacement: Replaces GB/T 11691-1989 and GB/T 2029-1980
2. Product Features
Material: Cast steel, with good corrosion resistance and strength, suitable for marine environments.
Connection Method: Flange connection, easy for installation and maintenance.
Sealing Form: Forced sealing, ensuring no leakage when the valve is closed.
Flow Direction: Unidirectional flow, preventing seawater backflow.
Driving Method: Manual drive, simple and convenient to operate.
3. Technical Specifications
Applicable Medium: Fresh water, seawater, etc.
Working Pressure: Medium pressure.
Working Temperature: Normal temperature.
Nominal Diameter: DN50~DN500, can be selected according to actual needs.
Structural Form: Center sealing structure, ensuring the stability and sealing performance of the valve.
4. Application Scope
The marine cast steel suction seawater valve GB/T2029-2008 is suitable for seawater suction systems in fields such as ships, offshore engineering, oil pipelines, oil tankers, etc. It is one of the important equipment to ensure the normal operation of ships.
5. Other Information
Inspection and Certification: The products have undergone strict quality inspection and certification to ensure compliance with relevant standards and requirements.
Maintenance and Upkeep: Regularly check the sealing performance and connection status of the valve to ensure it is in good working condition.
Packaging and transportation: The products are packed in a professional way to ensure they are not damaged during transportation.
