Help CenterReplaceable pH Electrode With BNC Connector for Easy Maintenance and Calibration
Related Products
-
High-Accuracy SZ 1140 pH Electrode Featuring Double Junction and Gel Filled DesignNegotiableMOQ: 100 Sets -
Industrial pH Electrode SZ 195.2 for Wastewater Treatment With High Temperature ResistanceNegotiableMOQ: 100 Sets
-
Food-Grade Conductivity Transmitter for CIP Cleaning Validation in Beverage ProductionNegotiableMOQ: 1 Set
-
Process Control C 3630 Conductivity Controller With 0-2000mS/cm Range and LCD DisplayNegotiableMOQ: 1 Set
-
Explosion-Proof C7335 Conductivity Transmitter ATEX Certified for Oil & Gas ApplicationsNegotiableMOQ: 1 Set
Established in 2015, Shanghai CAMP Environmental Protection Technology Co., Ltd. specializes in providing precision instrumentation solutions across global markets including North America, Europe, and Asia-Pacific. Our Replaceable pH Electrode with BNC Connector embodies our commitment to delivering reliable, user-centric equipment for environmental and industrial applications. This innovative probe addresses the core challenges of pH measurement maintenance through its modular design, significantly reducing operational downtime and ownership costs. Engineered in Shanghai, this electrode combines robust construction with practical serviceability to meet rigorous laboratory and field requirements.
Core Technical Advantages:
- Modular Replacement System - The electrode head can be detached independently from the BNC connector assembly, allowing cost-effective component renewal without replacing the entire unit.
- Calibration Efficiency - Features optimized gel electrolyte and low-impedance glass membrane that enable stable readings and simplified two-point calibration procedures.
- Enhanced Durability - Constructed with chemical-resistant epoxy body and reinforced cable junction to withstand harsh cleaning protocols and continuous industrial use.
Technical Specifications:
| Parameter | Specification |
|---|---|
| Measurement Range | 0 to 14 pH |
| Operating Temperature | 0°C to 80°C (32°F to 176°F) |
| Response Time | <30 seconds (90% response) |
| Zero Point | 7.00 pH ±0.25 |
| Slope | >96% |
| Pressure Limit | 0.5 bar |
The electrode's BNC interface ensures universal compatibility with most pH meters and controllers, facilitating seamless integration into existing monitoring systems. Its temperature compensation characteristics maintain accuracy across varying process conditions, while the replaceable junction design prevents clogging in high-solid samples. For users handling diverse media types, optional specialized glass formulations are available upon request.
Backed by Shanghai CAMP's extensive distribution network spanning 15 global markets including Oceania, South Asia, and Eastern Europe, this electrode undergoes strict quality validation before shipment. Our technical support team provides application-specific guidance to ensure optimal performance in your unique environment. Choose this solution to achieve:
- 40% reduction in annual maintenance costs compared to conventional electrodes
- Reduced inventory requirements through component-level replacement
- Extended service life through user-serviceable construction
Frequently Asked Questions:
Q: How often should I replace the electrode head?
A: Typical replacement intervals range from 6-18 months depending on usage frequency and sample composition. Reduced slope performance below 90% indicates replacement is needed.
Q: Is this compatible with autoclave sterilization?
A: The standard model withstands temperatures up to 80°C. For steam sterilization requirements, please inquire about our high-temperature variant.
Q: What calibration buffers are recommended?
A: We recommend pH 4.01 and 7.00 buffers for standard calibration. For high-precision applications, three-point calibration with pH 10.01 buffer is suggested.
Q: Can I use this electrode in viscous liquids?
A: Yes, the open junction design minimizes clogging. For samples with high solids content, consider our specialized flow-through models.
Q: What is the warranty period?
A: The electrode carries a 12-month manufacturer warranty against material defects.
Q: Do you provide custom cable lengths?
A: Standard cable is 1m. Custom lengths from 0.5m to 10m are available upon request.
Q: How should I store the electrode when not in use?
A: Always keep the glass bulb hydrated in storage solution or pH 4 buffer. Never store in distilled water.
Q: What distinguishes your replaceable design from competitors?
A: Our patented twist-lock mechanism ensures secure connection while preventing solution ingress, maintaining signal integrity throughout the electrode lifecycle.
