Help CenterPrime Quality Customized Q235 Q345 Q420 Q460 Q550 Q690 A36 SS400 ST52 Carbon Steel Welded Seamless Pipes Tubes Price
Related Products
-
Seamless Steel Pipe 4 Inch Sch80 8 Inch 6 Inch Pipe Seamless Carbon Steel Material Api 5l Gr B Psl2US$ 600 - 650MOQ: 10 Metric Tons -
China Manufacturer 2.5" 5" Large Diameter Thick Wall Seamless Tube 50mm Mild Steel Seamless Steel PipeUS$ 600 - 650MOQ: 10 Metric Tons
-
High Quality Seamless ERW Sch 40 80 Carbon Steel Galvanized Steel Pipe Welded 6M 9M TubeUS$ 600 - 685MOQ: 10 Metric Tons
-
High Quality ASTM Alloy Steel Seamless Round Pipe/Tube for Welding & Cutting Customizable LengthNegotiableMOQ: 10 Metric Tons
-
High Quality Seamless Style Steel Pipe Seamless Steel Tube Cold Rolled Seamless Steel PipeUS$ 550 - 720MOQ: 10 Metric Tons
Carbon Steel: Properties, Production, Examples and Applications
Carbon steel is an iron-carbon alloy, which contains up to 2.1 wt.% carbon. For carbon steels, there is no minimum specified content of other alloying elements, however, they often contain manganese. The maximum manganese, silicon and copper content should be less than 1.65 wt.%, 0.6 wt.% and 0.6 wt.%, respectively.
Types of carbon steel and their properties
Carbon steel can be classified into three categories according to its carbon content: low-carbon steel (or mild-carbon steel), medium-carbon steel and high-carbon steel . Their carbon content, microstructure and properties compare as follows:
| Carbon content (wt.%) | Microstructure | Properties | Examples |
| Low-carbon steel | Ferrite, pearlite | Low hardness and cost. High ductility, toughness, machinability and weldability | |
| Medium-carbon steel | 0.25 – 0.60 | Martensite | Low hardenability, medium strength, ductility and toughness |
| High-carbon steel | 0.60 – 1.25 | Pearlite | High hardness, strength, low ductility |
Carbon Steel Description
Grade:
1)GB: Q195, Q215, Q235A, Q235B, Q235C, Q235D, Q255A, 255B, Q275, Q295A, Q295B, Q345B, Q345C, Q345D, Q345E, Q390A, Q390B, Q390C,Q390D, Q390E, Q420, Q420B, Q420C, Q420D, Q420E, Q460D, Q460E, Q500D, Q500E, Q550D, Q550E, Q620D, Q620E, Q690D, Q690E
2)EN: S185,S235JR, S275JR, S355JR, S420NL, S460NL S500Q, S550Q, S620Q, S690Q
3)ASTM: Grade B, Grade C, Grade D, A36, Grade 36, Grade 40, Grade42, Grade 50, Grade 55, Grade 60, Grade 65, Grade 80
4)JIS: SS330, SPHC, SS400, SPFC, SPHD, SPHE
PRODUCT DETAILS
| A53 Seamless & Welded Carbon Steel Pipe Description |
| ASTM A53 seamless steel pipe has high strength, good toughness, good processing performance and welding performance. A53 American standard seamless steel pipes are available in a wide range of specifications, with a wide range of outer diameters and wall thicknesses. Because ASTM A53 seamless carbon steel pipe has excellent material properties and good processing performance, it is widely used in petroleum, chemical industry, electric power, machinery manufacturing and other fields. For example, in the petrochemical industry, ASTM A53 steel pipes can be used to transport high-temperature and high-pressure oil, natural gas and other media. |
| A53 Seamless & Welded Carbon Steel Pipe Description | ||
| Product Name | A53 Seamless & Welded Carbon Steel Pipe | |
| Standard | EN/DIN/JIS/ASTM/BS/ASME/AISI etc. | |
| Outer Diameter | Seamless: 1/4"-36" | Welding: 21.3mm-3620mm |
| Round Tube: 1/2"-10" | Square Tube/Rectangular Tube: 15x15mm-400x600mm | |
| Wall Thickness | Seamless: 1.25mm-50mm | Welding: 1.65mm-65mm |
| Length | 3-12 meters, Support customization | |
| Surface Process | Bright, Polished, Black | |
| Other Services | Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc. |
| Chemical Composition | ||||||||||
| A53 | Grade | C | Mn | P | S | Cu | Ni | Cr | Mo | V |
| TypeS(Seamless) | A | 0.25 | 0.95 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
| B | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 | |
| TypeE(Resistance Welding) | A | 0.25 | 0.95 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
| B | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 | |
| TypeF(Furnace Welding) | A | 0.3 | 1.2 | 0.05 | 0.05 | 0.4 | 0.4 | 0.4 | 0.15 | 0.08 |
| Mechanical Properties | ||
| A53 | GradeA | GradeB |
| Tensile Strength Min.psi(MPa) | 48,000(330) | 60,000(415) |
| Yield Strength Min.psi(MPa) | 30,000(205) | 35,000(240) |
| Physical Performance | |||||||
| Density 20°C | Modulus of Elasticity Kn/² mm | Coefficient of Thermal Conductivity 20°C | Heat Capacity 20°C | Resistivity 20°C | |||
| Kg/dm³ | 20C° | 300C° | 400C° | 450C° | W/m K | J/kg K | Ωmm²/m |
| 7.85 | 210 | 192 | 184 | 179 | 51 | 461 | 0.2 |
| Scope of Application |
| Construction: underground pipeline, underground water, hot water transmission, mechanical processing, bearing sleeve, processing machinery parts, etc. |
| Electrical: natural gas transmission, hydroelectric fluid pipelines, anti-static pipes for wind farms, etc. |
Product Display
Product Application
Product Packaging
Factory Display
FAQ
Q:What about your price?
A:Our price is very competitive because we are a factory. Feel free to contact us if you are interested in our products.
Q:Can I go to your factory to visit?
A:Of course, we welcome customers from all over the world to visit our factory.
Q:What product information do I need to provide?
A:You need to provide the grade, width, thickness, coating and the number of tons you need to purchase.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.we accept the third party inspection absolutely.
Q:How about the delivery time?
A:Within 3-15 days after we confirm you requirement.
Q:What is your terms of payment ?
A:T/T, L/C at sight, Cash, Western Union are all accepted if you have other payment,please contact me.
Q: Do you provide samples?
A:Yes,we could offer the sample for you to test but please pay freight fee.
