HSL-B1 Single-barrel filtering and dewatering oil filter truck
: The HSL -B1 single-barrel filtering and dewatering oil filter truck is a mesh-filtering type oil filter truck, which is an improved version of the LUC , LUCA series oil filter trucks. Its β3 >200. It can control the oil pollution degree to NAS 5 - 8 levels. It has a large dirt-holding capacity and strong oil-passing ability. This oil filter truck is a mobile oil filtering device. It can regenerate, purify and refill the new and old oils that have been contaminated during transportation, storage and use.
Normally, new oil also needs to be filtered before use, and the oil in use must be filtered periodically to keep your equipment in good condition. In the past, without a suitable filtering tool, you could only change the oil frequently, which increased production costs and various losses.
The HSL-B1 single-barrel filtering and dewatering oil filter truck meets the requirements of the times and solves your increasingly urgent problems. Its advantages are high oil filtering accuracy, good efficiency, small size, convenient movement, simple operation, reasonable structure and high standardization degree. It is easy to replace the oil filter element. It can also recover and filter dirty oil as much as possible in a narrow space. It can perform filling filtration, regular oil change filtration and bypass circulation maintenance on the main oil tank and small oil tanks. It can also flush the system, which can reduce labor intensity, improve the production environment, reduce environmental pollution, save energy, and is a good choice for reducing consumption and tapping potential. Therefore, it is a safe and energy-saving new product.
Features and effects:
1. Adopts selected filter materials (optional dewatering filter element);
2. The filter is equipped with a bypass valve;
3. It has a pressure protection function. The equipment will automatically stop when overpressure occurs. It gives sound/ light alarm to prompt the replacement of the filter element;
4、 The coarse filter at the oil suction port protects the oil pump and extends the service life of the filter element;
5、 Adding a directional front wheel makes the movement more flexible and lightweight;
6、 Adding an oil pan and oil pipe fixing device reduces the possible environmental pollution to the site;
7、 Strong interchangeability
HSL-B1 Type single-barrel filtering and dewatering oil filter truck main technical parameters:
M odel |
HSL-B1-16 |
HSL-B1 -40 |
HSL-B1-63 |
HSL-B1- 100 |
HSL-B1- 150 |
HSL-B1- 200 |
HSL-B1- 300 |
P rocessing C apacity （ L/H ） |
1000 |
2400 |
3600 |
6000 |
9000 |
12000 |
18000 |
Operating Voltage / Capacity (V/KW) |
380/0.37 |
380/0.75 |
380/1.1 |
380/1.5 |
380/5.5 |
380/7.5 |
380/10 |
Applicable Viscosity (cSt) |
320 |
||||||
Operating Temperature ( ℃) |
90 |
||||||
Designed Working Conditions |
Offline or online filtration |
||||||
Medium |
Turbine oil, hydraulic oil, synthetic oil and other petroleum-based oils |
||||||
Oil Pipe Inlet / Outlet Size |
25 |
32 |
50 |
80 |
|||
Filtration accuracy |
1 , 3 , 5 , 7 , 12um( User's choice) |
||||||
Operating pressure ( Mpa ) |
0.5 |
||||||
Inlet pressure ( Mpa ) |
>-0 . 045 |
||||||
Body appearance mm |
560*400*960 |
650*650*1300 |
|||||
