Shanghai Sote Valve Co., Ltd., a trusted industrial valve manufacturer based in Shanghai, China, presents this high-performance Automatic Control Valve engineered for precise pressure management across diverse piping systems. Designed to operate reliably within 0.5-2.5 MPa pressure ranges, this valve ensures stable flow control while minimizing energy waste in critical industrial applications.
Core Technical Advantages:
Multi-Pipe Adaptability: Seamlessly integrates with various pipe diameters through configurable connection interfaces
Precision Pressure Control: Maintains system stability within ±2% of setpoint under fluctuating demand
Robust Construction: Manufactured with corrosion-resistant alloys for extended service life in harsh environments
Fail-Safe Operation: Automatic shutoff feature activates during pressure anomalies to protect downstream equipment
Key Performance Specifications:
| Parameter | Value | Benefit |
| Pressure Range | 0.5 - 2.5 MPa | Wide operational flexibility |
| Leakage Rate | Reduced fluid loss | |
| Response Time | Rapid system adjustment | |
| Temperature Tolerance | -20°C to 150°C | Suitable for extreme conditions |
The valve's modular design allows for field adjustments without full system shutdown, significantly reducing maintenance downtime. Operators benefit from visual position indicators and standardized mounting patterns that simplify installation across new or existing infrastructure.
Industry Applications Include:
Cooling water distribution networks
Steam supply management systems
Chemical processing pipelines
HVAC pressure balancing stations
Backed by Shanghai Sote Valve's technical expertise in fluid control solutions, this product undergoes rigorous quality verification at our Shanghai manufacturing facility. Our regional presence enables responsive technical support and customized adaptation to meet specific project requirements, including special material configurations or pressure ratings.
Frequently Asked Questions:
Q1: What pipe standards does this valve support?
A: Compatible with ANSI, DIN, and JIS standard piping through configurable end connections.
Q2: Can it handle corrosive media?
A: Optional stainless steel trim available for acidic or alkaline fluids.
Q3: What maintenance intervals are recommended?
A: Annual inspection suggested; actual frequency depends on operating conditions.
Q4: Is manual override included?
A: Standard models include emergency handwheel operation.
Q5: What's the lead time for custom orders?
A: Typically 4-6 weeks for specialized configurations.
Q6: Are installation kits provided?
A: Mounting hardware can be supplied upon request.
