Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Warranty:
12
Installation:
Platform Scale
Display Type:
LED
Contact Supplier Request Quote Chat Now
Shandong Xinaoxuan Heavy Industry
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shandong
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Warranty 12
Installation Platform Scale
Display Type LED
After-sales Service 12
The Weighing Method Dynamic Weighbridge
Scale Structure U-Type Steel
Operating Environment Non Explosion Proof Loadometer
Automation Non Automation
Sensor Digital Scale
Structure Mechanical and Electrical Scale
Lightning Protection Without Lightning Protection
Transport Package 1
Specification 1
Trademark China
Origin china
Classification

  1. By sensor output signal: Can be divided into analog truck scales and digital truck scales.

  2. By scale body structure: Can be divided into I-beam truck scales, T-beam truck scales, L-beam truck scales, U-beam truck scales, channel steel truck scales, and reinforced concrete truck scales.

  3. By weighing method: Can be divided into static truck scales and dynamic truck scales.

  4. By installation method: Can be divided into above-ground scales and pit scales.

  5. By scale platform structure: Can be divided into steel structure platforms and concrete platforms.

  6. By operating environment: Can be divided into explosion-proof truck scales and non-explosion-proof truck scales.

  7. By automation level: Can be divided into non-automatic truck scales and automatic truck scales.

Standard Configuration
It mainly consists of three core components: the load-bearing force transmission mechanism (scale body), high-precision load cells, and weighing indicator. In addition, optional accessories such as printers, large-screen displays, and weighing management software can be added according to different user requirements to meet the needs of higher-level data management and transmission.
Structural Performance

  • I-beam truck scales: High compression resistance and load-bearing capacity, with low risk of scale body failure, but the highest price.

  • T-beam truck scales: Combine the advantages of channel steel and I-beam, featuring high scale body strength, pressure-resistant panels, and high cost-effectiveness.

  • U-beam truck scales: Strong lateral force resistance and anti-torsion performance, with a bridge structure design at the bottom.

  • Channel steel truck scales: Equipped with two load-bearing beams at the bottom and sealing plates for tension, but with relatively poor load-bearing performance.

  • L-beam truck scales: Possess all the advantages of U-beam scales, suitable for use at the joints of extra-large truck scale bodies.

  • Reinforced concrete truck scales (also known as cement scales): Excellent corrosion resistance, rust-proof and maintenance-free, long service life, and good quality stability.

Nomenclature
Electronic truck scales are usually denoted as "SCS-×××", where:

  • The first S stands for above-ground scale;

  • C stands for force transmission structure (load cell);

  • The second S stands for digital display;

  • The following "×××" represents the maximum capacity.

    For example, SCS-80 indicates an electronic truck scale with a maximum capacity of 80 tons.

Features

  1. Digitization: Digital truck scales adopt RS485 bus technology, offering strong anti-interference capability and a transmission distance of not less than 2000 meters. A single system can connect up to 32 load cells.

  2. Intelligence: Automatically compensates and adjusts for errors caused by load imbalance and temperature changes. It features automatic fault diagnosis and error code prompts.

  3. Calibration Technology: Enables one-click automatic calibration of load imbalance (four corners) for the weighing device. It can be directly connected to a computer to display the weighing process, reducing potential faults in the weighing workflow.
