Help CenterEpoxy Resin APG Clamping Machine With Casting Mould for CP/TP Insulator Bushings
Related Products
-
Customizable Epoxy Resin Casting APG Clamping Machine for CT/PT Instrument Transformer Insulators Bushings SpoutsUS$ 38000MOQ: 1 Set -
Chinese Factory Vertical APG Clamping Machine for Epoxy Resin Embedded Poles Bushings Spout CTPTUS$ 31000MOQ: 1 Set
-
APG Clamping Machine Made in China for Epoxy Resin Transformer Bushings SpoutUS$ 36000MOQ: 1 Set
-
APG Clamping Injection Machine in China Manufacturer Customized With Mixing Machine for Transformer Insulator Bushings SpoutUS$ 36000MOQ: 1 Set
-
Semi Automatic APG Clamping Machine Chinese Maker Factory for High Quality CTPT Transformer InsulatorUS$ 36000MOQ: 1 Set
Wide Compatibility - Fits 600×800mm to 1200×1000mm molds for flexible production.
High-Voltage Ready - Perfect for 11-36kV insulators, bushings, and transformers.
Custom Strokes - Adjustable core travel (500mm+ needs a pit).
APG Precision - Auto pressure gelation for bubble-free epoxy.
Fast Curing - High-pressure process speeds up production.
Heavy-Duty Build - Steel construction for long-lasting use.
Industry-Proven - Trusted for power, energy, and rail parts.
Short, clear, and scannable - ideal for product pages!
Our engineers have over 30 years of technical experience and are highly renowned in the industry.
Advantages:
1.Electronic vacuum gauge more precision
2.Oil cycling heating surround pot, heated evenly
3.Thin film de-gassing, excellent vacuumize
4.Adopt frequency motor to control mixing speed, quick degassing uniform mixing
5.Compact structure, less space, flexible use
6.Triple safety design, The temperature control system has functions of temperature display, automatic temperature limiting, safety protection and so on
7.Use stirring and injection vehicle directly, it is convenient to useOur engineers have over 30 years of technical experience and are highly renowned in the industry.
we offer overseas on-site technique traning.
1. Offer epoxy resin production line consulting service.
2. Supply High quality APG machine, mixing device, APG&casting Mold, CT/PT winding machine.
3. Produce qualified samples with APG machine and molds before dispatch, guarantee APG machine and molds are in good condition.
4. One-site training APG technique till you control produce products by yourself.
| Model No | HAPG-860-2 |
| Clamp Plate Size | 800*600mm |
| Clamp Force | 18T |
| Min Max Clamp Plate Stroke | 1250*240mm |
| Upper&Lower core puller stroke | 760*350mm |
| Heating power | 24KW |
| Hydraulic Power Pack | 7.5KW |
| Mould Load Weight | 2T |
Send Inquiry to This Supplier
