Home > Instruments & Meters > Test Instrument > Test Machine > HST HENSGRAND PWS-250 250KN Dynamic Fatigue Tester Dynamic Fatigue Testing Machine
HST HENSGRAND PWS-250 250KN Dynamic Fatigue Tester Dynamic Fatigue Testing Machine
US$ 20993.70
1 Set
US$ 6997.90
≥2 Set
Key Specifications
Get Latest Price
Type:
Testing Machine
brand name:
HST
place of origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Computerized Metallic Materials High Frequency Cyclic Fatigue Testing MachineUS$ 384884.50 - 419874.00MOQ: 1 Set -
HST 5kn Computer Controlled Static and Dynamic Electric Fatigue Testing MachineUS$ 146955.90 - 174947.50MOQ: 1 Set
-
HST 50-1000kn HENSGRAND PWS-500 500KN Shock Absorber Fatigue Testing MachineUS$ 279916.00 - 328901.30MOQ: 1 Set
-
DPS-25B Dynamic and Static Leaf Springs/composite Slabs/plates Load Fatigue Compression Bend Test Bench/testing MachineUS$ 594821.50 - 622813.10MOQ: 1 Set
-
HWS-50 50kN Computer Control Electro-Hydraulic Servo Dynamic and Static Fatigue Testing MachineUS$ 384884.50 - 419874.00MOQ: 1 Set
brand name
HST
place of origin
Shandong, China
customized support
OEM, ODM, OBM
power
200
Protection Class
IP67
Voltage
380 V
warranty
1 YEAR
Load Capacity(kN)
250
Load
±1.0% of Reading
Displacement
±1.0% FS of Each File
Deformation
±1.0% of Reading
Range Of Frequency
0.1~15Hz / 20Hz / 50Hz
Stroke of Piston(mm)
±50
Distance Between Columns(mm)
500
Distance Between Grips(mm)
50-600
Power
380V three phase
Certificate
CE
HST HENSGRAND PWS-250 250KN dynamic fatigue tester dynamic fatigue testing machine
|
Model |
HWS-50 |
HWS-100 |
HWS-200 |
HWS-250 |
|
|
Load Capacity(kN)
|
Static
|
50 |
100 |
200 |
250 |
|
1.1 |
Dynamic |
±40 |
±80 |
±160 |
±160 |
|
Measurement
Accuracy
|
Load
|
±1.0% of Reading |
|||
|
1.2 |
Displacement |
±1.0% FS of Each File |
|||
|
1.3 |
Deformation |
±1.0% of Reading |
|||
|
Range Of Frequency
|
0.1~15Hz / 20Hz / 50Hz |
||||
|
Stroke of Piston(mm) |
±50 |
±50 |
±75 |
±75 |
|
|
Distance Between Columns(mm)
|
500 |
565 |
700 |
700 |
|
|
Distance Between Grips(mm)
|
50~600 |
||||
|
Specification of constant voltage servo pump station |
flow≥37L/min, 21Mpa, 380V three phase |
||||
|
|
|
|
|
