Home > Instruments & Meters > Test Instrument > Test Machine > Factory Direct Customized Chain Steel Strand Tensile Test Hydraulic Tensile Testing Machine
Factory Direct Customized Chain Steel Strand Tensile Test Hydraulic Tensile Testing Machine
US$ 200020.98
1 - 2 Set
US$ 193491.94
≥3 Set
Key Specifications
Get Latest Price
Type:
Testing Machine
Warranty:
12months, 1 Year
Brand Name:
HST
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HST Manufacturing Universal Tensile Strength Tester / Universal Testing Machine PriceUS$ 131210.63 - 138327.49MOQ: 1 Set -
WAW Electro-hydraulic Servo Universal Testing Machine 3000KN 4000KN Hydraulic Universal Testing Machine UTMUS$ 8500 - 23000MOQ: 1 Set
-
Hydraulic Universal Testing Machine, Standard Jaws for Tensile, Compressing, and Bending TesterUS$ 7500 - 18000MOQ: 1 Set
-
1000kn 2000kn 3000kn Automatic Computer Controlled Hydraulic Servo Universal Testing Machine Hydraulic Universal Testing MachineUS$ 7500 - 18000MOQ: 1 Set
-
Computer Servo Control Electronic Universal Testing Machine With Universal Testing Machine 60T on SaleUS$ 5000 - 25000MOQ: 1 Set
Warranty
12months, 1 Year
Brand Name
HST
Place of Origin
Shandong, China
Product name
Hydraulic universal test machine
Application
Tensile, comprssion, bending test, Universal Testing, Auto Testing, Plastic Testing, Textile Testing, Paper Testing, Strength Testing, Tensile Testing, Compression Testing, Impact Testing
Power supply
380V, 50HZ, 3P or customized
Sturcture
4 Columns 2 Ball Screws
Standard
ASTM , ISO, EN, GB, etc
Certificate
CE, ISO
Clamping method
Hydraulic clamp
Protection way
Overload, overcurrent, protection net, etc
Customized support
OEM, ODM
Voltage
380 V
Protection Class
IP65
Power
2.5KW
Accuracy
≤± 0.5%
Products Description
Application
LAW series Servo-hydraulic Universal Testing Machine is ideal for high-capacity steel wire tension testing, also can be used for compression, bend/flex, and shear testing.
It accords with the correspondent requirements of BS, EN, ISO,ASTM, JIS and many other testing methods. These frames feature dual spaces so users can quickly change between tension and compression testing without having to remove heavy fixtures.
Standards
Load meets or exceeds the following standards:ASTM E4, ISO7500-1, EN 10002-2, BS1610, DIN 51221.
Strain measurement meets or exceeds the following standards: ASTM E83, ISO 9513, BS 3846 and EN 1000
Strain measurement meets or exceeds the following standards: ASTM E83, ISO 9513, BS 3846 and EN 1000
Model |
LAW-600E |
LAW-1000E |
LAW-1200E |
||
Max. Load(kN) |
600 |
1000 |
1200 |
||
Structure |
Four Columns Two Ball Screws |
||||
Load Accuracy |
≤± 0.5% |
||||
Load Range |
1％～100％ |
||||
Load Resolution |
1/500000 |
||||
Deformation Measurement Range |
2%~100%FS |
||||
Displacement Resolution(mm) |
0.0025 |
||||
Max. Tension Test Space(mm) |
1350 |
1350 |
1350 |
||
Column Effective Spacing(mm) |
580 |
580 |
610 |
||
Max. Piston Stroke(mm) |
250 |
||||
Clamping Method |
Hydraulic Automatic Clamp |
||||
Specimen sizes (mm) |
1*7, Φ9.5-φ21.6 |
1*7, Φ9.5-φ21.6 |
1*19, Φ12.7-φ28.6 |
||
Compression Plate Size (mm) |
Φ 160 |
||||
Power Supply |
3-phase,AC380V, 50Hz (Can Be Customized) |
||||
