High Quality Flat Stranded Conductor Aluminum for Motor Windings Electrical Product Enameled Wire Wire
Negotiable
MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Conductor Material:
Aluminium Wire
Shape:
Round Wire
Application:
Transformer, Instrument, Electrical Equipment, Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
QingDao
Delivery Detail:
22 days
Related Products
-
Huaerda China Factory Wholesale 155 Polyurethane 0.420mm Aluminum Electromagnetic Coils Cable Flat ROHS Enameled Wire WireNegotiableMOQ: 1 Kilogram -
Aluminum Aluminum CLAD ALUMINIUM ALL SIZES AVAILABLE ENAMELED WIRE ENAMELEDNegotiableMOQ: 1 Kilogram
-
1mm 2mm 3mm Aluminum Class h 200 Degrees Aluminum for Electric Motor Winding Enameled Wire WireNegotiableMOQ: 1 Kilogram
-
SWG 16 17 18 19 20 Aluminum Lacquered Aluminum Magnet Train Enameled Wire WireNegotiableMOQ: 1 Kilogram
-
2UEW 155 0.02mm Super Thin Magnetic Aluminum for Winding Wire Enameled WireNegotiableMOQ: 1 Kilogram
Conductor Material
Aluminium Wire
Shape
Round Wire
Application
Transformer, Instrument, Electrical Equipment, Motor
Brand
Other, Huilong
Certification
ISO9001, ROHS
Insulation Level
H
High - Quality Flat Stranded Conductor Aluminum Enameled Wire for Motor Windings
1. Product Overview
This high - quality flat stranded conductor aluminum enameled wire is a revolutionary product in the electrical industry. Specifically designed for motor windings, it combines the excellent electrical conductivity of aluminum with advanced enamel insulation technology. The flat stranded design provides unique advantages over traditional round wires, making it an ideal choice for various electrical applications.
2. Conductor Material and Structure
- Conductor Material: The core conductor is made of high - purity aluminum wire. Aluminum is known for its lightweight nature, which significantly reduces the overall weight of the electrical equipment. Compared to copper, aluminum offers a cost - effective alternative without sacrificing much in terms of conductivity. The use of high - quality aluminum ensures stable electrical performance and long - term reliability.
- Flat Stranded Structure: The flat stranded design consists of multiple aluminum strands arranged in a flat formation. This structure increases the surface area of the conductor, which in turn improves the heat dissipation capacity. Heat is a major concern in motor windings, and the enhanced heat dissipation helps to maintain the efficiency and longevity of the motor. Additionally, the flat shape allows for more efficient use of space within the motor, enabling a more compact design.
3. Insulation Features
- Enamel Insulation: The wire is coated with a high - quality enamel insulation layer. This insulation provides excellent electrical insulation properties, preventing short - circuits and ensuring the safe operation of the motor. The enamel is resistant to high temperatures, chemicals, and mechanical stress.
- Insulation Level: It has an insulation level of H, which means it can withstand high operating temperatures. This is crucial for motor windings, as motors often generate a significant amount of heat during operation. The H - level insulation ensures that the wire can operate reliably even under extreme temperature conditions, reducing the risk of insulation breakdown and motor failure.
4. Applications
- Motor Windings: As the primary application, this wire is specifically tailored for motor windings. It can be used in a wide range of motors, including industrial motors, household appliance motors, and automotive motors. The flat stranded design and high - quality insulation make it suitable for both high - power and low - power motors.
- Other Electrical Equipment: In addition to motors, it can also be used in other electrical equipment such as transformers and instruments. The excellent electrical and thermal properties make it a versatile choice for various electrical applications where efficient power transmission and reliable insulation are required.
5. Quality and Certification
- Manufacturing Quality: The wire is manufactured by Shandong Huilong Electrical Material Co., Ltd., a well - established manufacturer with a history dating back to 1970. The company has a team of experienced technicians and a strict quality control system to ensure that each wire meets the highest standards of quality.
- Certifications: The product is certified with ISO9001, which guarantees that it is produced under a quality management system. It also complies with the ROHS standard, which means it is environmentally friendly, free from harmful substances such as lead, mercury, and cadmium. Moreover, the company holds a series of other production certifications, including HACCP, TL900, QS9000, SA8000, etc., demonstrating its commitment to quality and safety.
6. Market Reach
- Global Market: This high - quality flat stranded conductor aluminum enameled wire has a wide market reach. It is exported to North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid - East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, and South Asia. The product has gained a good reputation in the international market for its high quality and competitive price.
- Domestic Market: In addition to the international market, it also has a significant share in the domestic market. The company's long - standing presence in the industry and its commitment to quality have made it a trusted supplier for many domestic electrical equipment manufacturers.
In conclusion, this high - quality flat stranded conductor aluminum enameled wire is a top - notch product for motor windings and other electrical applications. Its unique design, excellent insulation, and wide market acceptance make it a valuable choice for any electrical project.
