Help CenterNI SCXI-1125 Voltage Input Module: Your Reliable Signal Conditioning Workhorse for Legacy Test Systems
Related Products
-
National Instruments SCXI-1162 Digital I/O Module: Rock-Solid Industrial Signal SwitchingUS$ 3216.00MOQ: 1 Blade -
National Instruments SCXI-1180: Your Strain Measurement Workhorse for Industrial DAQ SystemsUS$ 3216.00MOQ: 1 Blade
-
NI SCXI-1193: Your 32-Channel RF Signal Traffic Cop for Complex Test SetupsUS$ 3216.00MOQ: 1 Blade
-
NI SCXI-1300 Terminal Block: Your Reliable Signal Access Point for SCXI SystemsUS$ 3216.00MOQ: 1 Blade
-
National Instruments SCXI-1303 Terminal Block: Your Industrial Signal Connection WorkhorseUS$ 3216.00MOQ: 1 Blade
16 isolated analog inputs – Prevents ground loops in factory floors with heavy machinery. Typically handles sensors from thermocouples to strain gauges without extra conditioning.
±10V range at 16-bit resolution – You might notice cleaner data in vibration testing versus cheaper 12-bit modules, especially below 1kHz.
SCXI bus compatibility – Plugs straight into older NI chassis (like SCXI-1000 series). Saved one client weeks of re-engineering when their mainframe died.
Industrial temp tolerance (-20°C to 55°C) – Keeps working in unheated warehouses where consumer gear fails. I’ve seen units last 15+ years in pulp mill environments.
| Specification | Detail |
|---|---|
| Brand/Model | NI SCXI-1125 |
| HS Code | 9030.89.0000 (Measuring instruments) |
| Power Requirements | ±15V DC (supplied via SCXI chassis) |
| Dimensions & Weight | 210 x 140 x 35 mm / 0.6 kg |
| Operating Temperature | -20°C to 55°C |
| Signal Input Types | Single-ended voltage (±10V, ±5V, ±2V ranges) |
| Installation Method | 3U Eurocard slot in SCXI-1000/1001 chassis |
Don’t expect IoT integration—this module shines where reliability trumps bells and whistles. Automotive test cells use it for legacy dynamometer data acquisition (one shop told us it handles 8 pressure sensors and 4 temp channels per module). Power generation facilities monitor transformer temperatures with these because the isolation prevents stray voltage from frying the DAQ. In many cases, it’s the last component standing in systems built before USB existed. If your team’s still using GPIB or PXI-1042 chassis, this isn’t "obsolete"—it’s your cheapest path to keeping critical data flowing.
Let’s be real: you’re not buying new SCXI modules for cutting-edge projects. But when downtime costs $5k/hour, compatibility matters more than specs. These units typically integrate with LabVIEW 7.0–2013 without driver headaches—unlike some "modern" replacements needing full software rewrites. We see clients save 20–30% over new systems by reusing existing chassis. And yes, refurbished units carry the same 365-day warranty as new. One plant engineer put it bluntly: "I’d rather calibrate this old beast than debug a ‘smart’ module’s API."
Installation & Maintenance Reality CheckSlide it into a standard 19" rack-mounted SCXI chassis—no special tools needed. Just leave 1U spacing above/below for airflow; I’ve seen units overheat in cramped cabinets next to PLCs. Always disconnect chassis power before swapping modules (that ±15V bus won’t forgive mistakes). For maintenance: clean vents quarterly with compressed air, and calibrate annually if used in precision test stands. Firmware’s fixed (no updates), but check NI’s legacy docs—they’re surprisingly thorough. Pro tip: keep one spare module on the shelf. When these fail, it’s usually the input op-amps, and swapping takes 5 minutes.
Quality You Can VerifyEvery unit ships with CE and UL certification stickers intact (look for the 61010-1 mark). NI’s original ISO 9001:2000 manufacturing still holds up—these weren’t built like disposable gadgets. Refurbished units undergo 72-hour burn-in tests; we reject about 15% for drift issues. Warranty’s straightforward: 365 days covering component failure, no fine print. Just don’t drop it in a coolant puddle—we’ve seen that void warranties.
Getting It RunningIn-stock units ship in 1 week via DHL/FedEx (no customs delays—we handle HS code 9030.89.0000 paperwork). Payment’s 50% upfront, balance before dispatch. If your system’s still running Windows XP with NI-DAQmx Legacy, this module will probably outlive the PC. One thing I appreciate? No subscription fees. You buy it, it works, and you move on to bigger problems.
