Help CenterNational Instruments SCXI-1325 Terminal Block: Your Reliable Signal Routing Partner for Legacy Test Systems
Related Products
-
NI SCXI-1326 High-Voltage Terminal Block: Stop Field Wiring From Becoming Your NightmareUS$ 3216.00MOQ: 1 Blade -
NI-9505 Series: Reliable Brushless DC Motor Control for Industrial AutomationUS$ 3216.00MOQ: 1 Blade
-
National Instruments NI-9853: Your Reliable CAN Bus Workhorse for Industrial ControlUS$ 3216.00MOQ: 1 Blade
-
Nexcom NTCF22: Industrial Fiber Optic Gateway for Reliable Plant Floor CommsUS$ 3216.00MOQ: 1 Blade
-
National Instruments SCXI-1162HV: Your Go-To Digital Input Module for Gritty Industrial EnvironmentsUS$ 3216.00MOQ: 1 Blade
Vibration-resistant screw terminals – Unlike spring-clamp alternatives, these hold wires securely in high-shock environments (think compressor test beds). You might notice fewer intermittent faults during long-duration runs.
Modular channel grouping – Isolates signal types physically (thermocouples here, strain gauges there). Typically prevents cross-talk in dense racks where space is tight.
Tool-less cover removal – Swaps take seconds during calibration. In many cases, this shaves 15+ minutes off maintenance windows compared to older NI blocks requiring screwdrivers.
Backward-compatible pinout – Works with SCXI-1102 chassis from the early 2000s. Saved one client from scrapping their entire emissions testing rig last year.
| Parameter | Specification |
|---|---|
| Brand/Model | National Instruments SCXI-1325 |
| HS Code | 8537.10.9000 (Electrical control boards) |
| Power Requirements | None (passive component) |
| Dimensions & Weight | 102 x 71 x 38 mm / 180g |
| Operating Temperature | -40°C to +70°C |
| Signal Types | Thermocouples, RTDs, strain gauges, voltage |
| Installation Method | Snap-in to SCXI-112x/114x modules |
I've seen this block shine in three spots most folks overlook: First, in university labs clinging to NI DAQ cards for teaching – students constantly plug/unplug, and the screw terminals survive the abuse. Second, in oilfield pump monitoring where humidity corrodes cheaper connectors. One refinery engineer told me it outlasted two "modern" alternatives by 18 months. Third, in legacy HVAC calibration rigs; its compatibility with SCXI-1121 modules means you're not redoing sensor wiring when replacing a failed module.
Let's be real – you're not buying this for new designs. But when keeping aging systems alive, the 365-day warranty feels like insurance against supplier roulette. Most distributors treat these as obsolete, but we test every unit before shipping (including continuity checks across all 32 channels). That 1-week delivery on in-stock units? Crucial when your plant manager's breathing down your neck about downtime. Payment's straightforward: 50% upfront, balance before we ship via your choice of FedEx/UPS/DHL. No nasty surprises when the crate arrives.
Keeping It Running SmoothlySkip the fancy tools – just use a 2.5mm hex driver for terminals. In humid environments (like that paper mill I visited last month), dab a tiny bit of dielectric grease on contacts during quarterly checks. Never force it into the module; if it doesn't slide smoothly, realign the pins. And for heaven's sake, torque screws to 0.5 N·m – over-tightening cracks the housing. One maintenance lead swears by blowing compressed air through the vents every 6 months to prevent dust buildup from nearby grinding stations.
Built to Last, Certified for Peace of MindIt appears National Instruments stopped new certifications when they sunsetted the SCXI line, but every unit we ship still carries the original CE mark and meets RoHS 2 compliance. The housing's UL 94 V-0 rated – critical if you're mounting near hydraulic systems. Honestly, the real validation comes from field use: I've handled units pulled from 20-year-old test stands that still test within spec. That's why we stand behind them with our 365-day warranty – no fine print, just swap it if vibration or temperature finally takes its toll.
