Product Description: SLV Series Low Pressure Screw Air Compressor
SAIDS Energy-Saving Low Pressure Screw Air Compressor – Expertly Crafted for Textile, Cement, and Glass Industries
High pressure increases production costs due to pressure reduction requirements. To reduce carbon emissions and protect equipment quality, we have designed and manufactured an energy-saving series of low-pressure screw air compressors with working pressures of 0.5MPa, 0.4MPa, and 0.3MPa specifically for your industry. When your application requires pressure below 0.5MPa, you can install a low-pressure screw air compressor.
The SAIDS low-pressure screw air compressor is one of the first low-pressure grade products in China, with models and specifications meeting international standards. It is suitable for low-pressure applications with temperatures up to 70°C and humidity below 90%.
Features
Significant Energy Savings – High-performance low-pressure air compressor designed for compressed air requirements of 0.3-0.5MPa. This product provides power savings compared to 0.7MPa+ air compressors, reducing operating costs significantly.
Excellent Performance – High-performance low-pressure air compressor with specialized coolant cleaning after oil treatment.
Convenient and Efficient – All components are pre-installed within the unit, requiring no additional on-site installation, ready for immediate use.
| MODEL | Capacity (Mpa) | Capacity (m³/min) | Power (KW/HP) | Noise (dB(A)) | Outlet (INCH) | Dimension (WxDxH mm) | Weight (Kg) |
|---|---|---|---|---|---|---|---|
| SLV-50A | 0.3 | 11.5 | 37 | 70±2 | Dn100 | 2150x1500x1800 | 1600 |
| 0.4 | 8.5 | 37 | 70±2 | Dn100 | 2150x1500x1800 | 1600 | |
| 0.5 | 7.8 | 37 | 70±2 | Dn100 | 2150x1500x1800 | 1600 | |
| SLV-60A | 0.3 | 14.2 | 45 | 70±2 | DN100 | 2150x1500x1800 | 1800 |
| 0.4 | 11.5 | 45 | 70±2 | DN100 | 2150x1500x1800 | 1800 | |
| 0.5 | 10.5 | 45 | 70±2 | DN100 | 2150x1500x1800 | 1800 | |
| SLV-75A | 0.3 | 17.0 | 55 | 70±2 | DN125 | 2400x1600x2100 | 2300 |
| 0.4 | 14.5 | 55 | 70±2 | DN125 | 2400x1600x2100 | 2300 | |
| 0.5 | 13.5 | 55 | 70±2 | DN125 | 2400x1600x2100 | 2300 | |
| SLV-100A | 0.3 | 21.5 | 75 | 70±2 | DN125 | 2400x1600x2100 | 2500 |
| 0.4 | 20.0 | 75 | 70±2 | DN125 | 2400x1600x2100 | 2500 | |
| 0.5 | 16.5 | 75 | 70±2 | DN125 | 2400x1600x2100 | 2500 | |
| SLV-120A | 0.3 | 28.5 | 90 | 70±2 | DN150 | 2700x1850x2100 | 3200 |
| 0.4 | 25.0 | 90 | 70±2 | DN150 | 2700x1850x2100 | 3200 | |
| 0.5 | 21.5 | 90 | 70±2 | DN150 | 2700x1850x2100 | 3200 | |
| SLV-150A | 0.3 | 34.0 | 110 | 70±2 | DN150 | 3200x2150x2400 | 3500 |
| 0.4 | 28.0 | 110 | 70±2 | DN150 | 3200x2150x2400 | 3500 | |
| 0.5 | 23.0 | 110 | 70±2 | DN150 | 3200x2150x2400 | 3500 | |
| SLV-175A | 0.3 | 45.0 | 132 | 70±2 | DN150 | 3200x2150x2400 | 3600 |
| 0.4 | 32.0 | 132 | 70±2 | DN150 | 3200x2150x2400 | 3600 |
| MODEL | Capacity (Mpa) | Capacity (m³/min) | Power (KW/HP) | Noise (dB(A)) | Outlet (INCH) | Dimension (WxDxH mm) | Weight (Kg) |
|---|---|---|---|---|---|---|---|
| 0.5 | 29.0 | 132 | 70±2 | DN150 | 3200x2150x2400 | 3600 | |
| SLV-200A | 0.3 | 50.5 | 160 | 70±2 | DN200 | 3650x2350x2500 | 4500 |
| 0.4 | 45.0 | 160 | 70±2 | DN200 | 3650x2350x2500 | 4500 | |
| 0.5 | 34.0 | 160 | 70±2 | DN200 | 3650x2350x2500 | 4500 | |
| SLV-250A | 0.3 | 56.5 | 185 | 70±2 | DN200 | 3650x2350x2500 | 4800 |
| 0.4 | 48.5 | 185 | 70±2 | DN200 | 3650x2350x2500 | 4800 | |
| 0.5 | 45.0 | 185 | 70±2 | DN200 | 3650x2350x2500 | 4800 | |
| SLV-280A | 0.3 | 61.5 | 200 | 70±2 | Dn200 | 4000x2400x2650 | 5500 |
| 0.4 | 53.5 | 200 | 70±2 | Dn200 | 4000x2400x2650 | 5500 | |
| 0.5 | 45.0 | 200 | 70±2 | Dn200 | 4000x2400x2650 | 5500 |
The Energy-Saving Low Pressure Screw Compressor Series is Your Optimal Choice
Frequently Asked Questions (FAQs)
What is a low-pressure screw air compressor?
A low-pressure screw air compressor is a type of air compressor designed to deliver compressed air at lower pressure levels, typically below 100 psi. These compressors utilize rotary screw technology, which provides a continuous and reliable source of low-pressure air, making them ideal for various industrial applications requiring consistent airflow.
How does a rotary screw air compressor work?
A rotary screw air compressor works by using two interlocking helical screws to compress air. The air is drawn in through an inlet and then trapped between the screws as they rotate, reducing its volume and increasing its pressure. This method is efficient and allows for a steady output of compressed air, which is particularly useful in low-pressure applications.
