Electrical Supplies High Temperature Resistance Class 200 Enameled Aluminium Winding Wire AWG 16 for Transformer Coils Peru
US$ 3.90
500 - 4999 Kilograms
US$ 3.50
≥5000 Kilograms
Key Specifications
Get Latest Price
Type:
Insulated
Insulation Material:
polyester-imide, Polyamide imide
Conductor Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Electrical Supplies China Factory UL Approve Class 200 Enameled Aluminum Round Wire For TransformerUS$ 3.45 - 3.85MOQ: 500 Kilograms -
Electrical Supplies 6.0 mm IEC-60317 Enameled Aluminum Round Electrical Wires Manufacturing Price for Transformer PeruUS$ 3.92 - 4.02MOQ: 500 Kilograms
-
Electrical Supplies Aluminum Winding Wire UL Certified Enameled Electrical Wires AWG EI/AIW 200/220 for Magnetic CoilUS$ 3.60 - 3.90MOQ: 500 Kilograms
-
Electrical Supplies ISO9001 Certification Aluminum Enameled Wire Polyamideimide Composite Polyester Enamel Aluminum Coil WindingUS$ 3.59 - 3.89MOQ: 500 Kilograms
-
Electrical Supplies UL Certification Aluminum Enameled Wire With Polyamideimide Composite Polyester Enamel CoatingUS$ 3.60 - 3.85MOQ: 500 Kilograms
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Solid
Model Number
Q(ZY/XY)-200
Brand Name
YONGDONG
Place of Origin
Shandong, China(Mainland)
Diameter:
awg
Style:
Enameled Aluminum Wire
Shape:
Round
Heat-resisting class:
C class
Insulation Material:
polyester-imide, Polyamide imide
Production Range:
0.50mm-5.00mm
Certification:
ULE234565 ROHS REACH
Bobbin:
PT25 PT30 PT60 PT200 PT270
Product name
Enameled Aluminum Wire
Color
Brown
Product Description
Round Wire Diameter: 0.5mm-5.00mm (4awg-24awg) Magnetic wire swg
Product Name: 2020 Hot Class 200 AWG16 for transformer coils,enamelled aluminium winding wire
Gauge Class 155-180-200-220 Enameled Aluminum Round Wire Price for Rewinding of Motors
AWG15 Round Enamelled Aluminum Wire Used For Washing Machine Motors Winding
High Quality Enameled Round aluminum 18 AWG Magnet Wire
Quality certification wholesale china suppliers aluminum enamel round winding wire
Top Quality Reasonable Price Class EIW Round Enamelled Copper Clad Aluminum Winding Wire in Coil Electrical Wire
NEMA IEC JIS standard AWG6 to AWG32 Enameled Aluminum round wire for coil winding
0.2mm 5.0mm enameled round aluminum magnet wire/cable for sizes
Product Name |
QZ(G)-155 |
QZ-180 |
Q(ZY/XY)-200 |
Q(ZY/XY)-220 |
Thermal Class |
155, class F |
180, class H |
200, class C |
220, class C |
Coating Material |
PEW(G) |
EIW |
EI/AIW |
EI/AIW |
Cross Section Range (mm) |
0.20-5.00 |
0.20-5.00 |
0.20-5.00 |
0.20-5.00 |
Insulation Thickness (IEC) |
Grade 1
Grade 2
Grade 3
|
Grade 1
Grade 2
Grade 3
|
Grade 1 Grade 2 Grade 3 |
Grade 1 Grade 2 Grade 3 |
Standard |
GB/T6109.2
GB/T23312.4
IEC60317-3
|
GB/T6109.5
GB/T23312.5
IEC60317-8
NW30
|
GB/T6109.20
GB/T23312.7
IEC60317-13
NW35
|
GB/T6109.22
IEC60317-46
NW16
|
PT200 spool |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
