UL Certificated Aluminum Aluminum Coil Winding Wire for Motors and Transformers Winding Philippines
US$ 4.52
500 - 4999 Kilograms
US$ 4.01
≥5000 Kilograms
Key Specifications
Get Latest Price
Type:
Insulated
Insulation Material:
polyester-imide, Polyamide imide
Conductor Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RoSH Certification Enameled Aluminum Round Wire for Fan Motor and Transformer Aluminum Coil Winding Wire PhilippinesUS$ 3.96 - 4.36MOQ: 500 Kilograms -
UL Certificated Aluminum Enameled Wire Magnetic Wire for Motors and Transformers Aluminum Coil Winding Wire PhilippinesUS$ 3.95 - 4.45MOQ: 500 Kilograms
-
Aluminum Coil Winding Wires Top Quality Best Sellers Aluminum Enameled Wire for Motors and Transformer PhilippinesUS$ 3.89 - 4.39MOQ: 500 Kilograms
-
Insulated Winding Wire Aluminium Coil for Ceiling Fan Motor and Transformer Electrical Wires PhilippinesUS$ 3.89 - 4.39MOQ: 500 Kilograms
-
High Temperature Resistance Class 200 AWG16 for Transformer Coils Enameled Aluminium Winding Wire PhilippinesUS$ 3.96 - 4.46MOQ: 500 Kilograms
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Solid
Model Number
EIW 180
Brand Name
YONGDONG
Place of Origin
Shandong, China(Mainland)
Diameter:
awg
Style:
Enameled Aluminum Wire
Shape:
Round
Heat-resisting class:
H class
Insulation Material:
polyester-imide, Polyamide imide
Production Range:
0.50mm-6.00mm
Certification:
ROHS REACH ISO9001
Bobbin:
PT25 PT30 PT60 PT200 PT270
Product name
Enameled Aluminum Wire
Color
Brown
Product Description
Round Wire Diameter: 0.5mm-6.00mm (3awg-24awg) Magnetic wire swg
Product Name |
QZ(G)-155 |
QZ-180 |
Q(ZY/XY)-200 |
Q(ZY/XY)-220 |
Thermal Class |
155, class F |
180, class H |
200, class C |
220, class C |
Coating Material |
PEW(G) |
EIW |
EI/AIW |
EI/AIW |
Cross Section Range (mm) |
0.50-6.00 |
0.50-6.00 |
0.50-6.00 |
0.50-6.00 |
Insulation Thickness (IEC) |
Grade 1
Grade 2
Grade 3
|
Grade 1
Grade 2
Grade 3
|
Grade 1 Grade 2 Grade 3 |
Grade 1 Grade 2 Grade 3 |
Standard |
GB/T6109.2
GB/T23312.4
IEC60317-3
|
GB/T6109.5
GB/T23312.5
IEC60317-8
NW30
|
GB/T6109.20
GB/T23312.7
IEC60317-13
NW35
|
GB/T6109.22
IEC60317-46
NW16
|
PT200 spool |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
