Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > SWG7 Aluminum Winding Wire Enameled 130 155 180 200 220 Class Africa
SWG7 Aluminum Winding Wire Enameled 130 155 180 200 220 Class Africa
US$ 3.50
500 - 4999 Kilograms
US$ 3.40
5000 - 17999 Kilograms
US$ 3.30
≥18000 Kilograms
Key Specifications
Get Latest Price
Type:
Insulated
Insulation Material:
EI/AIW
Conductor Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Use for Microwave Oven Motor Enamel Aluminum Magnet Wire AfricaUS$ 3.29 - 3.50MOQ: 500 Kilograms -
High Quality Enameled Aluminum Wire With More Than 180/200/220 Heat-resistant GradesUS$ 3.85 - 4.15MOQ: 5 Kilograms
-
High Quality,wide Range of Application of 180 Class Enameled Aluminum Wire AmericaUS$ 2.8 - 4.3MOQ: 1 Ton
-
3mm Enamelled Aluminum Winding Wire PakistanUS$ 3.75 - 4.30MOQ: 100 Kilograms
-
Class 220 Enameled Aluminum Round Wire IEC60317 Aluminum Magnet Wire Aluminum Winding Wire Power TransformersUS$ 3.65 - 3.85MOQ: 500 Kilograms
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Solid
Model Number
Q(ZY/XY)-200
Brand Name
YONGDONG
Place of Origin
Shandong, China(Mainland)
Diameter:
4.5mm
Style:
Enameled Aluminum Wire
Shape:
Round
Heat-resisting class:
C class
Insulation Material:
polyester-imide, Polyamide imide
Production Range:
0.20mm-4.5mm
Certification:
UL ROHS REACH ISO9001
Bobbin:
PT25 PT30 PT60 PT200
Product Description
Round Wire Diameter: 0.5mm-6.0mm (5awg-32awg/7swg-35swg)
Product Name: 7 awg enamelled aluminium round wire
Product Name | QZ(G)-155 | QZ-180 | Q(ZY/XY)-200 | QY-220 |
Thermal Class | 155, class F | 180, class H | 200, class C | 220, class N |
Coating Material | PEW(G) | EIW | EI/AIW | AIW |
Cross Section Range (mm) | 0.2-4.5 | 0.2-4.5 | 0.2-4.5 | 0.2-4.5 |
Insulation Thickness (IEC) | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 |
Standard | GB/T6109.2 GB/T23312.4 IEC60317-3 | GB/T6109.5 GB/T23312.5 IEC60317-8 NW30 | GB/T6109.20 GB/T23312.7 IEC60317-13 NW35 | GB/T6109.22 IEC60317-46 NW16 |
