Help CenterSchneider Morton KNX7301650 Xenta 731 Controller
Related Products
-
Schneider Morton KNX5104BCL C-Bus CouplerUS$ 999MOQ: 1 Unit -
Schneider 5500DMX C-Bus Unidirectional DMX GatewayUS$ 999MOQ: 1 Unit
-
Schneider L5504AMP 4-Channel Analog Output ModuleUS$ 999MOQ: 1 Unit
-
Schneider Morton KNX L5508D1AP 8-Channel 1A Dimmer Without Bus Power SupplyUS$ 999MOQ: 1 Unit
-
Schneider Morton KNX L5508RVF 8-Channel 10A Smart Relay With Built-in Bus Power SupplyUS$ 999MOQ: 1 Unit
Supports LonWorks TP/FT-10 network communication.
Supports Modbus (serial and TCP/IP) communication — a key advantage of the Xenta 731 compared with some lower models.
Supports MicroNet / I/NET networks (mentioned in some documentation).
Supports Ethernet TCP/IP connection, with a built-in web server for remote monitoring and control access.
I/O Module Expansion Capability
The Xenta 731 itself is a CPU/controller module and does not include a large number of physical I/O points.
It can be expanded with up to 20 Xenta 400 series I/O modules.
In a LonWorks network, it can support approximately 30 subordinate Xenta 280/300/401 modules.
Embedded Web Server Function
Users can access controller status, alarms, trends, and setpoints via a standard web browser.
Supports trend logs, alarm handling, schedules, and graphical display functions.
High-Performance Control Applications
Capable of running multiple control application instances (e.g., HVAC, lighting, and building management systems).
Supports short control cycles (e.g., 100 ms) for higher real-time performance.
Compatible with TAC XBuilder / Menta programming tools.
Installation / Environmental Specifications
Power supply: 24 VAC ± 20 % (50/60 Hz) or 19–40 VDC.
Power consumption: approximately 5 W (transformer rated at about 5 VA).
Mounting: DIN-35 mm rail or wall-mounted.
Operating temperature: typically 0 °C to +50 °C.
Typical Application Scenarios
Serves as the core controller/server node in large building automation systems such as HVAC, lighting, ventilation, and energy monitoring.
Used in projects that require integration of multiple networks (LonWorks, Modbus, MicroNet, Ethernet) with web-based remote monitoring and alarm functions.
Commonly integrated with TAC Vista and other building management platforms as a data aggregation and reporting node.
