Unwinding – Feeding the raw material from a master roll.
Slitting – Cutting into multiple narrow strips using rotary blades or laser cutting.
Rewinding – Collecting slit strips onto smaller cores for assembly.
Quality Control – Ensuring precision width, tension control, and defect detection.
| Jumbo width | Max.570mm | Finished roll widtb | Min.5mm |
| Jumbo roll diameter | Max.350mm | Finished roll diameter | Max.50mm |
| Jumbo roll core dia | 6inch/3inch | Finished roll core dia | 9mm |
| Film thickness | 12um | Max.speed | 100m/min |
| Rewind shaft | 4 solid shafts | Slitting blade | By circular blades |
| Web guiding | Edge/Line control | Leader table | Automatic operation |
| PLC&Touch panel screen | Import/Domestic | Supply power | 380V AC,50~60Hz |
| Machine dimension | 2600*2100*1650(mm) | Air pressure | 0.6~0.8MPa |
A correction tape slitter is a specialized industrial machine designed for precision cutting and processing of correction tape materials. It is a critical component in the manufacturing process, ensuring that wide rolls of correction tape film (typically made of PET, PP, or adhesive-coated materials) are accurately slit into narrow, uniform strips suitable for use in correction tape dispensers.
Where excellence meets trust-partner with us for sustainable growth!
Delish' s senior R&D team is made up of first-class elites from the industry that have abundant experience in product design and performance control. We have many patents and seek for ever greater perfection throughout the process including R&D, production, measurement and control to ensure that the products are smarter, safer and more efficient.
Delish insists on"Change to meet changes".Driven by customers'actual demand,our core R&D team specializes in auto equipment drawing design,program composition.custom development of electrical equipment, independent production at high-end CNC machining center, precision assembly and debugging,and strict process management in order to ensure that all functions pass the test and that the equipment is suitable for continuous,stable production toachieve customer value maximization.
Delish provides intelligent factory upgrade solutions to meet customer demand,and builds an effective connection with customers'operational systems including ERP for intelligent operational task assignment to realize auto and intelligent production to help the customers improve their operational eficiency.
Delish adopts international famous-brand components and conducts balance control during machine installation in accordance with high-precision requirements to ensure the stability of tension for product slitting at high speed.
Our professional marketing service team offerall-round pre-sale,in-sale,and after-sale services.Our 24-hour response system ensures that we provide a timely analysis and solution for customers.
