Rewinding controlled by servo motors; auto and digital tension control.
Rewinding shaft: 1 inch air shaft 2pcs; 3 inch air shaft 2pcs. Air shaft or Slipping shaft for choosing.
Rewinding part is design in double station 4 shafts, non stop rewinding with auto turret and auto cutting fnished roll function.
Blade and blade shaft: Razor blade or Round Blade for choosing or pneumatic blade for choosing.
Joint table using method one: use for jumbo roll replace or joint.It can design in manual/auto mode.
Joint table using method two: use for fnished roll labeling. It candesign in manualauto mode.
Can add the dust sucking device in separately, improve the dust in end face and dust flying out.
| Jumbo width | 400~1350mm | Finished roll width | Min.20mm |
| Jumbo roll diameter | Max.700mm | Finished roll diameter | Max.350mm |
| Jumbo roll core dia | 6inch | Finished roll core dia | 3inch |
| Film thickness | 4~30μm | Max.speed | 50~500m/min |
| Rewind shaft | air shafts | Slitting blade | By circular blades |
| Web guiding | Edge control | Joint table | Manual operation |
| PLC&Touch panel screen | Import/Domestic | Machine dimension | 3800*3400*2000mm |
An aluminium foil slitter is a specialized industrial machine designed to cut and rewind large master rolls of aluminium foil into narrower strips with precise widths. It plays a crucial role in industries requiring customized foil dimensions for packaging, insulation, and electronic applications.
Where excellence meets trust-partner with us for sustainable growth!
Delish' s senior R&D team is made up of first-class elites from the industry that have abundant experience in product design and performance control. We have many patents and seek for ever greater perfection throughout the process including R&D, production, measurement and control to ensure that the products are smarter, safer and more efficient.
Delish insists on"Change to meet changes".Driven by customers'actual demand,our core R&D team specializes in auto equipment drawing design,program composition.custom development of electrical equipment, independent production at high-end CNC machining center, precision assembly and debugging,and strict process management in order to ensure that all functions pass the test and that the equipment is suitable for continuous,stable production toachieve customer value maximization.
Delish provides intelligent factory upgrade solutions to meet customer demand,and builds an effective connection with customers'operational systems including ERP for intelligent operational task assignment to realize auto and intelligent production to help the customers improve their operational eficiency.
Delish adopts international famous-brand components and conducts balance control during machine installation in accordance with high-precision requirements to ensure the stability of tension for product slitting at high speed.
Our professional marketing service team offerall-round pre-sale,in-sale,and after-sale services.Our 24-hour response system ensures that we provide a timely analysis and solution for customers.
