FSP2005/70 Freesor-current Sensor
≥1 Units
- T/T
- 14 days
You May Like
Product Details
| Certification | CE | Output Signal Type | Analog Output | |
| Customized | Customized | Type | Electromagnetic | |
| Application | Switching Power Supply | Trademark | freesor | |
| Origin | China |
Product Description
(Parameter) | (Symbol) | (Unit) | (Min) | (Type) | (Max) | (Comment) |
RatedprimaryDCcurrent | IPNDC | A | -3000 | -- | 3000 | |
RatedprimaryACcurrent | IPN | A | -- | -- | 2122 | |
Measuringrange | IPM | A | -3000 | -- | 3000 | |
Measuringresistance | RM | Ω | 0 | -- | 1 | |
Secondarysidecurrent | IS | A | -1 | -- | 1 | |
Overloadcapacity① | ?? | kA | -7 | -- | 7 | @100ms |
Currentratio | KN | -- | 1:3000 | -- | ||
Supplyvoltage | UC | V | ±23 | -- | ±25 | |
Currentconsumption | IC | mA | -- | -- | 50 | |
Outputnoise0...10Hz② | Vno | ppm | -- | -- | 10 | |
Outputnoise0...100Hz② | -- | -- | 30 | |||
Outputnoise0...1kHz② | -- | -- | 50 | |||
Zerooffsetcurrent② | IOE | ppm | -100 | -- | 100 | |
Temperaturedriftcoefficient | TCIOE | ppm/K | -20 | -- | 20 | |
Zerobiasstability② | ppm/month | -10 | -- | 10 | ||
Linearity | εL | ppm | -50 | -- | 50 | |
Currentfollowingvelocity | di/dt | A/μs | 100 | -- | -- | |
Bandwidth(±3dB) | BW | kHz | -- | 60 | -- | @0.5%IPM |
