Help CenterFSM200L2F-Freesor-current Sensor
Related Products
Electricaldata：（Ta=25℃，Vc=±15VDC） | |
|
Parameter Ref |
FSM200L2F |
RatedinputIPN(A) |
±200 |
MeasuringrangeIP(A) |
0～±500 |
TurnsratioNP/NS(T) |
1：2000 |
OutputcurrentIs(mA) |
±100*IP/IPN |
SecondarycoilresistanceRS(Ω) |
@TA=+25℃21.0 |
@TA=+85℃25.0 | |
InsideresistanceRM(Ω) |
@TA=+85℃[(VC-0.6V)/(IS*0.001)]-RSmax |
SupplyvoltageVC(V) |
(±12~±15)±5% |
AccuracyXG(%) |
@IPN,T=25°C |
OffsetcurrentIOE(mA) |
@IP=0,T=25°C |
TemperaturevariationofIOE(mA) |
@IP=0,-40~+85°CTYP |
MagneticoffsetcurrentIOH(mA) |
@IP=0→3*IPN |
Linearityerrorεr(%FS) |
|
Di/dtaccuratelyfollowed（A/µs） |
>100 |
Responsetimetra(µs) |
@90%ofIPN |
PowerconsumptionIC(mA) |
@±15V17+Is |
BandwidthBW(KHZ) |
@-3dB,IPN |
DC-100 |
InsulationvoltageVd(KV) |
@50/60Hz,1min,AC |
6.0 |
Generaldata： | |
Parameter |
Value |
OperatingtemperatureTA(°C) |
-40~+85 |
StoragetemperatureTS(°C) |
-55~+125 |
MassM(g) |
78 |
Plasticmaterial |
PBTG30/G15,UL94-V0; |
Standards |
IEC60950-1:2001 |
EN50178:1998 | |
SJ20790-2000 | |
