HIMA F3 AIO 8 01 (F3AIO8401) – Safety‑related Analog I/O Module for HIQuad/F3 Systems

HIMA F3 AIO 8 01 (F3AIO8401) – Safety‑related Analog I/O Module for HIQuad/F3 Systems thumbnail-1
HIMA F3 AIO 8 01 (F3AIO8401) – Safety‑related Analog I/O Module for HIQuad/F3 Systems thumbnail-2
HIMA F3 AIO 8 01 (F3AIO8401) – Safety‑related Analog I/O Module for HIQuad/F3 Systems photo-1
HIMA F3 AIO 8 01 (F3AIO8401) – Safety‑related Analog I/O Module for HIQuad/F3 Systems photo-2
US$ 2216.00 ≥1 Blade
Key Specifications
Get Latest Price
I/O Number:
HIMA F3AIO8401
Place of Origin:
America
Communication Interface:
Modubus
Contact Supplier Request Quote Chat Now
Xiamen Xiongba E-commerce Co., LTD
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
I/O Number HIMA F3AIO8401
Place of Origin America
Communication Interface Modubus
Model Number HIMA F3AIO8401
Condition NEW
Warranty One Year
Package Original Packaging
HS Code 853710
Order Placement Process & Guarantees

  • Warranty: 365 days

  • Lead time: 1 week if in stock; no more than one month at the latest

  • Payment: 50% advance payment, full payment prior to delivery

  • Express options: FedEx, UPS, DHL

Key Features

  • Safety‑related analog I/O in one card: Combines analog inputs and outputs, typically configurable for current or voltage loops to reduce slot count.

  • 8 configurable channels: In many cases set as 4–20 mA or 0–10 V; helps standardize field signals across ESD/BMS loops.

  • SIL‑focused design: Engineered for safety applications; suitable for SIL 3 architectures when used as specified in HIMA documentation.

  • Backplane integration: Communicates via the F3/HIQuad backplane—no extra comms wiring to the CPU.

  • Diagnostics & status LEDs: Quick visual state makes loop checks and fault isolation faster during turnarounds.

  • HIMA ecosystem compatibility: Works within H41q/H51q/HIQuad systems, preserving existing cabinet layouts and wiring practice.

  • Serviceable front connector: Front plug connector simplifies commissioning and module swaps without disturbing field terminations.

Technical Specifications
Brand / Model
HIMA F3 AIO 8 01 (F3AIO8401)
HS Code
8537.10 (Boards/panels for electric control, ≤1000 V)
Power Requirements
24 V DC via F3/HIQuad backplane; module consumption typically ≤ 5 W
Dimensions & Weight
3U Eurocard plug‑in format; standard F3 rack depth (typical 160 mm)
Operating Temperature
0 to +60°C (typical industrial range)
Signal I/O Types
8 analog channels, configurable as current (e.g., 4–20 mA) or voltage (e.g., 0–10 V) for input/output
Communication Interfaces
F3/HIQuad backplane bus; front status LEDs
Installation Method
Plug‑in module for HIMA F3/HIQuad racks; front plug connector for field wiring

Note: Specific limits vary by firmware and system configuration. If you need confirmed resolution, accuracy, or channel assignment tables, we’ll check against your exact CPU/rack revision.
