Help CenterHIMA F3 DIO 8/8 01 (F3DIO8801) – Compact 8DI/8DO 24 VDC Module for HIQuad/HIQuad X Safety Systems
Related Products
-
HIMA F6215 – High‑Precision 8‑Channel Analog Input Module for Safety‑Critical MonitoringUS$ 2216.00MOQ: 1 Blade -
HIMA F6216 – Precision Analog Input Module for Safety Control SystemsUS$ 2216.00MOQ: 1 Blade
-
HIMA F7130A F7130 Power Supply Module – Stable Backplane Power for Safety Controller RacksUS$ 2216.00MOQ: 1 Blade
-
HIMA F8620/11 High‑Efficiency Central Processing Unit for Safety ControllersUS$ 2216.00MOQ: 1 Blade
-
HIMA F8650A Advanced Safety Control Module – Robust Logic for High‑integrity Protection LayersUS$ 2216.00MOQ: 1 Blade
Warranty: 365 days
Lead time: 1 week if in stock; not more than one month latest
Payment: 50% advance; balance before delivery
Express shipping: FedEx, UPS, DHL
8 DI + 8 DO in one slot: Consolidates common ESD, interlock, and utility I/O points without expanding the rack.
24 VDC field level: Matches typical plant instrumentation (prox switches, pushbuttons, solenoid valves).
Backplane-powered logic: No separate logic power wiring; the rack supplies the module via the system bus.
Designed for safety systems: Suitable for HIMA HIQuad/HIQuad X architectures; supports SIL-rated applications when engineered per IEC 61508/61511.
Channel diagnostics: Input/output channel status indication helps maintenance teams pinpoint issues faster.
Compact, single-slot footprint: Frees cabinet space compared with separate DI and DO cards.
Robust field isolation: Galvanic isolation at the field interface (per channel group) to reduce cross-channel interference.
| Brand / Model | HIMA F3 DIO 8/8 01 (F3DIO8801) |
|---|---|
| HS Code | 853890 (Parts for industrial control apparatus) |
| Power Requirements | Logic power via HIQuad/HIQuad X backplane; external 24 VDC field supply for outputs |
| Signal Input/Output Types | 8 × DI (24 VDC), 8 × DO (24 VDC, transistor) |
| Communication Interfaces | System backplane bus (no front communication ports) |
| Installation Method | Plug-in module for HIMA HIQuad/HIQuad X rack; field wiring via detachable terminal block |
| Operating Temperature | 0 to +60 °C (typical for F3 modules) |
| Dimensions & Weight | Single-slot F3 form factor; approx. 0.3 kg |
This module is typically used where you need a compact mix of digital signals inside safety-related systems:
Oil & Gas: ESD panels, fire & gas skids, compressor interlocks, blowdown valve control
Chemicals & Petrochemicals: pump permissives, tank overfill protection, SIL-rated shutdowns
Power Generation: turbine ancillary systems, boiler trip logic, balance-of-plant interlocks
Pharma & Fine Chemicals: utility skids, inerting systems, safe shutdown of critical equipment
Marine & Offshore: topside ESD/F&G, emergency ventilation and damper control
From my experience, it’s a neat fit for small clusters of I/O on remote panels—things like limit switches, ESD pushbuttons, beacon/sounder outputs, and solenoid valves that you want in one tidy slice of the rack.
“Swapping to the F3 DIO 8/8 01 saved us a card position and simplified our loop drawings,” a maintenance supervisor told us after a turnaround on an offshore platform.
Space and cost efficiency: One module covers small DI/DO clusters, often reducing rack slots and terminal count.
Lifecycle continuity: Compatible with HIMA HIQuad/HIQuad X environments, which typically eases migration and spares strategy.
Diagnostics for faster turnaround: Channel status cuts troubleshooting time during SATs or during proof testing.
Risk reduction: Designed for safety applications; follows IEC safety principles when used in approved architectures.
Supportable integration: Works cleanly with standard 24 VDC field devices—no exotic accessories required in most cases.
Cabinet & rack: Install in a compatible HIMA HIQuad/HIQuad X rack. Provide adequate ventilation; keep ambient within 0–60 °C.
Wiring practice: Use 24 VDC PNP-style sensors for DI in most cases; protect DO circuits with appropriately sized fuses or breakers for solenoids, lamps, and horn loads.
Grounding & EMC: Bond shield drains at one end, segregate I/O and power wiring, and maintain clean grounding to avoid nuisance trips.
Field power: Outputs require stable 24 VDC field supply; check common returns and group allocation before commissioning.
Safety precautions: De-energize field power before replacing the front connector; verify function with approved test procedures.
Routine checks: Periodic proof testing per IEC 61511, terminal re-torque during turnarounds, and cleaning of dust with dry air. Firmware checks as applicable to the system controller.
Spares strategy: Keep at least one spare per panel or per ten installed modules—this seems to minimize downtime in many plants.
CE compliant; RoHS-aligned design
Suitable for SIL 3 applications when used within certified HIMA architectures (IEC 61508/61511)
Manufacturing under ISO 9001 quality systems
Warranty: 365 days
HIMA HIQuad/HIQuad X racks and power supplies (for system backplane power)
Detachable front terminal blocks for field wiring (matching the F3 form factor)
Complementary I/O: F3 DI and F3 DO single-function cards if channel density needs to scale
You might notice that this module hits a practical sweet spot: enough points for small packages, robust enough for safety service, and straightforward to commission with standard 24 VDC devices. If you’re consolidating a few interlocks and solenoids into one rack slot, it usually pays for itself in saved space and wiring time.
