Wafer butterfly Valve range:
Production DN40~DN800
Pressure:PN10/PN16
Wafer butterfly Valve standard:
Design Standard:DIN3354
Face to Face:DIN2501
Flange Standard:DIN3202
Testing Standard:EN12226/ISO5208
Material of parts:
Body:Cast Iorn/Ductile Iron
Stem:2Cr13/SS304/SS316/Carbon Steel
Disc:Ductile Iron,Stainless Steel
Seat:NBR,EPDM,PTFE,RPTFE
Introduction
The Wafer Butterfly Valve with Seat Options NBR/EPDM/PTFE/RPTFE is a remarkable solution designed specifically for industrial fluid control. Engineered to meet the diverse needs of various industrial applications, this valve offers exceptional performance, reliability, and flexibility. With its advanced design and high - quality materials, it stands as a top - choice product in the industrial fluid management market.
Company Background
This wafer butterfly valve is manufactured by Chengxin Valve Co., Ltd., a well - established manufacturer since 1993. The company holds significant production certifications such as ISO9001, ISO14000, and OHSAS18001, which guarantee the high - quality and safety standards of the products. With an annual export share ranging from US$1 Million - US$1.5 Million, it has a strong presence in major international markets including South America, Eastern Europe, Africa, and the Mid East. The company also has overseas offices, which enables better communication and service for international customers. A team of 1 - 10 experienced sales representatives is dedicated to providing excellent customer support.
Design and Structure
Wafer Connection Form: The wafer design of this butterfly valve allows for easy installation between two flanges. This connection form not only saves space but also reduces the overall weight of the piping system. It is a cost - effective and efficient solution for industrial fluid control systems, as it can be quickly and securely installed without the need for complex additional structures.
Butterfly Disc: The butterfly disc is the core component of the valve. It is precisely engineered to provide smooth and accurate flow control. When the valve is open, the disc rotates to allow the fluid to pass through with minimal resistance. In the closed position, it effectively blocks the flow, ensuring tight shut - off.
Seat Options
One of the most significant features of this valve is the multiple seat options available:
NBR (Nitrile Butadiene Rubber): NBR seats offer good resistance to oil, fuel, and other petroleum - based products. They are suitable for applications where the fluid contains a certain amount of oil or grease. NBR also has excellent abrasion resistance, which helps to extend the service life of the valve.
EPDM (Ethylene Propylene Diene Monomer): EPDM seats are known for their outstanding resistance to weathering, ozone, and UV radiation. They are ideal for applications where the valve is exposed to the outdoor environment or in systems handling water - based fluids. EPDM also has good chemical resistance to many acids and alkalis.
PTFE (Polytetrafluoroethylene): PTFE seats provide excellent chemical resistance to a wide range of corrosive substances, including strong acids, bases, and solvents. They have a very low coefficient of friction, which results in smooth operation of the valve and reduces wear on the valve components.
RPTFE (Reinforced Polytetrafluoroethylene): RPTFE seats combine the chemical resistance of PTFE with enhanced mechanical properties. The reinforcement materials improve the strength and dimensional stability of the seat, making it suitable for high - pressure and high - temperature applications.
Application Scope
Industrial Usage: This valve is widely used in various industrial sectors such as chemical processing, power generation, and food and beverage production. In chemical plants, it can handle different types of corrosive chemicals safely. In power generation facilities, it helps to control the flow of steam, water, and other working fluids.
Water Industrial Usage: In the water treatment and distribution industry, the valve is essential for regulating the flow of water. It can be used in water supply systems, sewage treatment plants, and desalination plants. The different seat options allow it to be customized according to the specific water quality and treatment requirements.
Performance and Reliability
The wafer butterfly valve is designed to offer long - term reliable performance. It has a high flow coefficient, which means it can handle large volumes of fluid with low pressure drop. The valve is also tested rigorously to ensure its tight shut - off capability, preventing any leakage. Its robust construction and high - quality materials make it resistant to wear, corrosion, and erosion, reducing the need for frequent maintenance and replacement.
Technical Specifications
Pressure Rating: The valve can withstand a wide range of pressures, typically from low - pressure applications up to medium - high pressure depending on the specific model and seat material.
Temperature Range: The temperature range varies according to the seat material. For example, NBR seats are suitable for temperatures between - 40°C to 100°C, while PTFE seats can handle temperatures from - 200°C to 260°C.
Size Range: The valve is available in a variety of sizes to meet different flow rate requirements. Sizes typically range from small - diameter valves for laboratory or small - scale industrial applications to large - diameter valves for major industrial pipelines.
Installation and Maintenance
Installing the wafer butterfly valve is relatively straightforward. It can be easily inserted between two flanges and tightened using bolts. Regular maintenance mainly involves checking the valve for any signs of wear, leakage, or damage. If necessary, the seat or other components can be replaced without much difficulty, which helps to keep the valve in optimal working condition.
Customer Support
Chengxin Valve Co., Ltd. provides comprehensive customer support. The sales manager, LI, can be contacted via WhatsApp at +8618333988751 or by mobile phone at 86 - 13231988751. The company is committed to answering all customer inquiries promptly and providing technical assistance throughout the product's lifecycle. Whether it is pre - sales consultation, installation guidance, or after - sales service, the company ensures that customers receive the best possible support.
In conclusion, the Wafer Butterfly Valve with Seat Options NBR/EPDM/PTFE/RPTFE is a high - performance, versatile, and reliable solution for industrial fluid control. Its multiple seat options, wide application scope, and excellent technical specifications make it a valuable asset for any industrial fluid management system.
