Help CenterEATON MP3010 Motor Protection Relay – Reliable Protection and Diagnostics for Low-Voltage Motors
Related Products
-
EATON XV-440-10TVB-1-20 Touch Screen Controller – 10.4-inch HMI-PLC for Reliable Machine Visualization and ControlUS$ 1216.00MOQ: 1 Blade -
EATON XV-442-57CQB-1-10 Touch Screen Controller – Compact 5.7-inch HMI for Machine Visualization and PLC ConnectivityUS$ 1216.00MOQ: 1 Blade
-
Eaton XVH-340-57CAN-1-10 Touch Panel HMI – 5.7-inch CANopen Operator Interface for Compact, Reliable Machine ControlUS$ 1216.00MOQ: 1 Blade
-
Eaton XVH-340-57MPI-1-13 Touch Panel – Compact 5.7-inch HMI for MPI-based PLC ApplicationsUS$ 1216.00MOQ: 1 Blade
-
ProSoft 5204-DFNT-PDPMV1 – High‑Speed EtherNet/IP (DFNT) to PROFIBUS DP‑V1 Gateway for Fast PLC–Fieldbus IntegrationUS$ 1216.00MOQ: 1 Blade
Warranty: 365 days
Lead time: 1 week if in stock; no more than 1 month at the latest
Payment: 50% advance payment; full payment prior to delivery
Express options: FedEx, UPS, DHL
Comprehensive motor protection – Overload (thermal model), phase loss, phase unbalance, jam/stall, and ground fault (with appropriate CT), helping prevent nuisance trips and equipment damage.
CT-based current monitoring – Works with 1 A or 5 A secondary CTs, which makes it easy to adapt to different motor sizes without changing the relay.
Clear alarms and trip records – You might notice faster troubleshooting because the relay stores cause-of-trip details and status indicators that maintenance can read quickly.
Programmable I/O – Typically includes digital inputs and multiple Form C relay outputs, so you can tie trips and alarms to PLCs, MCC starters, or remote annunciation.
Communication-friendly – RS‑485 Modbus RTU is common, with expandability to fieldbus (if equipped) for plants standardizing on network diagnostics.
Flexible installation – Panel/door-mounted format with terminal blocks suits MCC buckets or wall-mount control panels; wiring is straightforward.
Setpoints that match the process – From start-time supervision to overload class and unbalance thresholds, parameters can be dialed in to match motor duty.
| Brand / Model | EATON MP3010 Motor Protection Relay |
| HS Code | 8536.49 (Relays for electrical control/protection, other) |
| Power Requirements | Auxiliary 24 VDC nominal (typically 18–30 VDC). Some MP3000-series variants support 100–240 VAC auxiliary—verify the nameplate for your MP3010 unit. |
| Dimensions & Weight | Panel-format relay; front ~96 × 96 mm, depth ~110 mm; approx. 0.8–1.0 kg (typical for this series). |
| Operating Temperature | -20 to +60 °C (typical application range) |
| Signal Input/Output Types | 3-phase current via CTs (1 A/5 A); digital inputs; programmable Form C relay outputs for trip/alarm; 4–20 mA analog output if equipped; optional RTD inputs on higher variants. |
| Communication Interfaces | RS‑485 Modbus RTU (commonly used). Optional fieldbus gateways (e.g., Profibus DP, DeviceNet) may be available depending on configuration. |
| Installation Method | Panel/door mounting with screw terminals. Wire CT secondaries (1 A or 5 A) and auxiliary supply as per the terminal layout. Use in an enclosed cabinet (IP54 or better recommended). |
| Protection Functions | Thermal overload, phase loss, phase unbalance, jam/stall protection, ground-fault (with appropriate sensing configuration). |
The MP3010 fits low-voltage motor control centers and standalone panels across water/wastewater (pumps, blowers), HVAC (chillers, cooling towers), mining and aggregates (conveyors, crushers), chemical and pharma (agitators, mixers), and general manufacturing (fans, extruders, compressors). One thing I appreciate is how predictable it is in pump stations: you can tighten the jam/stall window to protect against dry-run or blocked impellers without tripping on normal start-up inrush.
Reliable protection – Stable algorithms reduce nuisance trips while still reacting fast to genuine faults.
Easy retrofit – Works with standard 1 A/5 A CTs and typical MCC wiring, so upgrade projects move quickly.
Compatibility – Integrates with PLCs and SCADA over Modbus RTU; in many cases, no gateway is needed.
Cost control – Fewer motor failures and shorter diagnostics time generally translate to lower maintenance spend.
Supportable long-term – Parameters are transparent; technicians can adjust setpoints without proprietary software in most cases.
Panel environment – Mount in a clean, ventilated enclosure; maintain ambient within the specified temperature range.
Wiring practices – Keep CT secondary leads twisted and short; land shielded comms cables for RS‑485. Always short CT secondaries before servicing.
Protection coordination – Coordinate trip curves with upstream breakers/fuses and downstream contactors or soft starters.
Routine checks – Verify tightening torque on terminals every maintenance cycle; review trip logs monthly for early warnings.
Calibration & firmware – Confirm CT ratios and overload class after motor changes; update firmware if the unit supports it and your site policy allows.
Safety – De-energize auxiliary supply and follow lockout/tagout procedures before making adjustments or wiring changes.
The MP3010 series is typically supplied with CE marking and UL/cUL recognition for industrial control equipment. RoHS compliance is standard for most recent builds. Manufacturer’s warranty is 12 months (365 days) under normal use. If you need a formal certificate pack (Declaration of Conformity, UL file reference), we can include it with the shipment or provide it in advance for approvals.
From the fieldA food & beverage client swapped legacy thermal overloads on their conveyor line for MP3010 units and reported fewer unplanned stops. What stood out to them was the unbalance alarm: it alerted maintenance to a loose lug before it turned into a motor failure. That seems to be where the MP3010 pays for itself—in catching issues early without constantly tripping the line.
