Help CenterGE DS200KLDBG1ABC LED Display Board – Status and Keypad Display Interface for Mark V / GE Industrial Drive Panels
Related Products
-
GE DS200FGPAG1AHD Gate Pulse Amplifier Board — Reliable Firing Control for GE Drive and Excitation BridgesUS$ 3216.00MOQ: 1 Blade -
GE DS200DSPCH1ADA Digital Signal Processor Control Board – High‑speed Loop Control for GE Drive and Turbine SystemsUS$ 3216.00MOQ: 1 Blade
-
GE DS200KLDCG1AAA LED Display Board – Front-panel Status and Keypad Interface for GE DS200-based Drives and ControlsUS$ 3216.00MOQ: 1 Blade
-
GE DS200LDCCH1ALA LAN Communication Card – Stable Plant Networking for GE Drive/Excitation SystemsUS$ 3216.00MOQ: 1 Blade
-
GE DS200LDCCH1ANA – Drive Control / LAN Communication Board for GE Industrial Drives and ExcitersUS$ 3216.00MOQ: 1 Blade
Warranty: 365 days
Delivery: 1 week if in stock; no more than 1 month at the latest
Payment: 50% advance payment; full payment prior to delivery
Express options: FedEx, UPS, DHL
LED status and numeric display: Clear, high‑visibility indicators for alarms, modes, and numeric values typically used by operators.
Keypad interface support: Works with the panel keypad to navigate menus, acknowledge alarms, and input setpoints.
Direct ribbon-cable connection: Internal harnessing to the controller/backplane simplifies installation—no external comm ports required.
Drop‑in replacement: Designed for DS200/Mark V cabinets, reducing commissioning time and risk.
Revision “ABC” hardware: Later revision within the KLDBG1A series that, in many cases, improves component robustness and availability.
Service-friendly layout: You might notice labeled connectors and test points that make troubleshooting faster.
| Brand / Model | GE DS200KLDBG1ABC (LED Display Board, KLDBG1A series) |
| System Compatibility | GE Mark V Speedtronic and selected GE DS200‑based drive/excitation panels (internal display/keypad interface role) |
| HS Code | 8538.90 (Parts suitable for the apparatus of heading 8535/8536/8537) |
| Power Requirements | Typically 5 VDC logic supply from backplane; power draw commonly |
| Operating Temperature | 0 to 60 °C (typical cabinet rating; ensure adequate ventilation) |
| Signal Input/Output Types | LED drivers and display segments; keypad scan/return lines; TTL‑level logic interfaces via internal ribbon connectors |
| Communication Interfaces | Internal only (ribbon cable to controller/logic board); no external field comms on this module |
| Installation Method | Mounts inside the panel with standoffs; mates to backplane/logic via keyed ribbon connectors; ESD‑safe handling required |
Gas and steam turbine control panels using GE Mark V Speedtronic hardware
Industrial drive and excitation systems where local LED indication and keypad input are required
Power generation, oil & gas, and process industries standardizing on GE DS200‑series controls
Lifecycle extensions and field spares for legacy GE cabinets needing form‑fit‑function display modules
Reliability: Robust LED indication and stable keypad scanning help reduce nuisance faults, especially in older cabinets.
Compatibility: Fits the KLDBG1A family footprint; typically works without code changes when replacing the same series.
Lower downtime: Drop‑in mechanical fit and keyed connectors keep swap time short during planned outages.
Cost control: Extends service life of installed Mark V panels—often a more economical route than a full upgrade.
Supportability: Clear labeling and standard GE ribbon interfaces make OEM‑style troubleshooting familiar to technicians.
Cabinet environment: Install in a clean, dry, ventilated panel. Maintain ambient within the cabinet’s specified temperature range.
Wiring & connectors: Use ESD precautions. Seat ribbon cables fully; follow keying to avoid reversed connections. Verify strain relief.
Mounting: Secure to standoffs/guides. Avoid mechanical stress on the display segments and headers.
Power-up checks: After installation, verify 5 VDC logic supply is within tolerance and inspect LED test sequences if available.
Routine care: Dust with dry, non‑static brushes; check connector oxidation annually. No routine calibration is typically required.
Firmware: This board usually has no field‑upgradable firmware; updates, if any, are handled at the controller level.
Safety: Isolate power before service. Follow site lockout/tagout procedures.
Typically used within CE‑compliant cabinets; components commonly meet UL/CSA recognition at the system level
RoHS status varies by production date and revision; many later boards trend toward RoHS‑compliant components
365‑day warranty coverage as stated above
Each unit can be function‑tested prior to dispatch on request
If you’re replacing an earlier KLDBG1A variant, share your current part/revision and cabinet type. We’ll double‑check ribbon mappings and mounting hardware so your swap is as quick and uneventful as it should be.
