Help CenterBently Nevada 140734-05 Dynamic Pressure Monitor (3500/72M)
Related Products
-
Bently Nevada 1900/27 Series Vibration Monitor – Compact, Reliable Protection for General-Purpose Rotating MachineryUS$ 3216.00MOQ: 1 Blade -
Bently Nevada 136719-01 Earthing I/O Module – Reliable Shield Grounding for 3500 RacksUS$ 2216.00MOQ: 1 Blade
-
Bently Nevada 1900/55 Fan Monitor – Purpose-built Protection and Condition Monitoring for Industrial FansUS$ 3216.00MOQ: 1 Blade
-
Bently Nevada 1900/65A-00-00-01-00-00 General Purpose Equipment Monitor – Compact Machinery Protection for Pumps, Fans, and MotorsUS$ 3216.00MOQ: 1 Blade
-
Bently Nevada 1900/65A-00-00-02-00-01 – General Purpose Equipment Monitor for Reliable Vibration ProtectionUS$ 3216.00MOQ: 1 Blade
• Warranty period: 365 days
• Delivery time: 1 week if in stock; no more than one month at the latest
• Payment method: 50% advance payment; full payment before delivery
• Express delivery: FedEx, UPS, DHL
4-channel dynamic pressure monitoring – Typically supports four independent dynamic pressure inputs for machinery and combustion analysis.
IEPE/ICP-type sensor compatibility – Works with common constant-current excited dynamic pressure transducers used on gas turbines and reciprocating compressors.
Programmable filtering and measurements – Configure band/overall measurements (e.g., RMS, peak, peak-to-peak) for pulsation and instability detection.
Alert/Danger setpoints per channel – Channel alarms integrate with 3500 system relays, helping you automate trips and interlocks at the rack level.
Buffered outputs – Front-end or rear I/O buffered BNC outputs for portable analyzers or commissioning checks without disturbing signals.
4–20 mA trending (when configured) – In many cases, proportional 4–20 mA outputs are available on the I/O for easy DCS trending.
Seamless 3500 integration – Uses the 3500 rack backplane; configuration and data via 3500/22M TDI into System 1 or DCS (Modbus/TCP).
Industrial temperature rating – Designed for cabinet-mounted use in typical plant environments.
| Brand / Model | Bently Nevada 140734-05 (3500/72M Dynamic Pressure Monitor) |
| HS Code | 9031.80.00 (Measuring or checking instruments – reference classification) |
| Power Requirements | Supplied by 3500 Rack backplane; no external power supply required |
| Channels | 4 dynamic pressure channels, individually configurable |
| Signal Input/Output Types | IEPE/ICP-type dynamic pressure inputs; buffered outputs (BNC); 4–20 mA outputs via I/O (when enabled) |
| Communication Interfaces | Via 3500/22M TDI: Ethernet to System 1 / Modbus TCP to DCS (typical) |
| Installation Method | Installs in a 3500 rack slot with corresponding rear I/O module; shielded cabling recommended |
| Operating Temperature | 0 to +65 °C (module); indoor cabinet mounting |
| Dimensions & Weight | 3500 plug-in module; occupies one rack slot; approx. 0.5 kg |
You might notice that dynamic pressure becomes essential wherever combustion stability or gas pulsation affects performance and reliability. Typical scenarios:
Gas turbines – combustion dynamics and thermoacoustic instability trending
Centrifugal compressors – pulsation monitoring near surge and antisurge control tuning
Reciprocating compressors – valve dynamics, pulsation bottles, and crosshead pressure events
Pipelines and high-pressure manifolds – pressure pulsation and resonance detection
Test stands and R&D skids – high-bandwidth pressure signal capture for diagnostics
Feedback from a refinery maintenance engineer: “We added the Bently Nevada 140734-05 to capture pulsations during startup. Trend plots became far more stable, and we stopped chasing false surge events.”
Advantages & ValueDrop-in for existing 3500 racks – Minimizes engineering changes and shortens commissioning windows.
High signal integrity – Buffered outputs and stable excitation help keep data clean for diagnostics.
Alarm integration – Alert/Danger setpoints route to system relays, so protection logic stays centralized.
Lifecycle and serviceability – In many cases, spares, I/O, and firmware support are consistent across the 3500 family, simplifying upkeep.
Total cost of ownership – Using the existing TDI/Ethernet path saves on gateways, wiring, and DCS point engineering.
Cabinet and rack – Mount in a 3500 rack within a 19" cabinet. Keep ambient within 0–65 °C with adequate ventilation.
Wiring practices – Use shielded cables for sensor inputs; maintain good earth bonding; avoid running signal wiring parallel to high-voltage lines.
I/O and buffering – Route portable analyzer access through the buffered BNCs to prevent disturbing live signals.
Configuration – Set units (kPa/psi), filters, and alarm setpoints carefully; verify scaling against a known reference during commissioning.
Routine care – Periodically back up configuration, check connectors for looseness, clean dust from the rack, and apply approved firmware updates through the TDI when available.
Spares – Keeping one spare 140734-05 and an I/O module on hand typically shortens MTTR in critical services.
CE marked; UL/cUL recognized; RoHS compliant (typical for 3500-series modules)
Manufactured for industrial environments and continuous operation
Warranty: 365 days (as supplied)
