Help CenterProSoft AN-X2-AB-DHRIO – Bridge EtherNet/IP to Allen‑Bradley DH+/RIO for Fast, Low-Risk Migrations
Related Products
-
ASML MC1AB37 (4022.437.1856) – Control Module for Precision Mechatronics in Lithography SystemsUS$ 3660.00MOQ: 1 Combo -
Autoliv Gtw.Mod. B0110 (627697900B) – Gateway Module for Vehicle SRS/CAN-LIN NetworksUS$ 4660.00MOQ: 1 Combo
-
Autoliv Sim.Mod. B0760 (627913600B) – Simulation Module for Airbag/Restraint ECU TestingUS$ 4660.00MOQ: 1 Combo
-
Bachmann MPC270-128512M Processor Module for M1 – Real-time Control for Reliable Machine and Energy AutomationUS$ 4216.00MOQ: 1 Blade
-
Basler DECS-200-1L Digital Excitation Controller – Precise AVR and PF/VAR Control for Synchronous GeneratorsUS$ 4216.00MOQ: 1 Blade
Warranty: 365 days
Delivery time: 1 week for in-stock; no more than one month at the latest
Payment: 50% advance payment; full payment for delivery
Express options: FedEx, UPS, DHL
EtherNet/IP to DH+ / RIO bridging – Connects Logix controllers over EtherNet/IP to legacy PLC‑5/SLC nodes (DH+) and Remote I/O racks.
Migration-friendly design – Typically lets you keep blue-hose wiring and existing I/O while upgrading CPUs, trimming risk and project hours.
Deterministic I/O data mapping – Cyclic data exchange to RIO adapters and straightforward mapping into CIP assemblies for Logix.
Web-based configuration and diagnostics – You can view network health, node status, and perform setup through a built-in web interface.
Dual 10/100 Ethernet ports – Simple line-topology connection to plant networks and controllers; useful during staged cutovers.
Status LEDs for fast troubleshooting – Clear indicators for power, Ethernet link/activity, and DH+/RIO communication.
DIN-rail mount, 24 VDC power – Compact, panel-ready module suited to typical control cabinets.
Firmware upgradable – Update features and stability without replacing hardware; usually done via the web UI.
| Brand / Model | ProSoft Technology / AN-X2-AB-DHRIO |
| HS Code | 8517.62 (Data communication apparatus) |
| Power Requirements | 24 VDC nominal (typical control-cabinet supply) |
| Dimensions & Weight | Compact DIN-rail enclosure; approx. handheld size, light-weight for panel mounting |
| Operating Temperature | Typically -20°C to +60°C |
| Signal Input/Output Types | 1× DH+ / RIO (3‑pin blue‑hose interface), 2× 10/100Base‑T Ethernet (RJ45), status LEDs |
| Communication Interfaces | EtherNet/IP to Logix controllers; DH+ node connectivity; Remote I/O scanner/adaptor bridging; web server for setup/diagnostics |
| Installation Method | DIN-rail mounting in an IP20 control cabinet; front-access connectors |
Typical use is in brownfield modernization where PLC‑5 or SLC systems remain on DH+ or Remote I/O. That often includes automotive body/paint shops, consumer goods packaging, food & beverage, metals, water/wastewater, and mid‑speed material handling. One thing I appreciate is how it helps maintain PanelView terminals and RIO racks during phased CPU swaps to ControlLogix, reducing risk on validated processes.
Customer note: “We migrated two PLC‑5 lines over a weekend. The AN‑X2‑AB‑DHRIO kept the remote Flex I/O running while the new CompactLogix came online. No rewiring of the blue hose, and production was ready Monday morning.”
Reliability – Purpose-built for Rockwell migrations; stable operation on long DH+/RIO runs.
Compatibility – Works with common legacy AB devices and Logix platforms over EtherNet/IP.
Cost savings – Typically avoids wholesale I/O replacement and new field wiring.
Time-to-value – Short commissioning curve with web tools and straightforward data mapping.
Supportability – Firmware updates and structured diagnostics simplify lifecycle maintenance.
Cabinet & environment – Install on DIN rail in a clean, dry IP20 enclosure; allow ventilation space around the module.
Power & grounding – Use a stable 24 VDC supply with proper panel grounding; keep network shields and earth bonds consistent.
Wiring – For DH+/RIO blue hose, maintain correct polarity and terminators as per AB guidelines; keep Ethernet runs within spec and segregated from high-noise conductors.
Network setup – Assign static IPs where appropriate; document node addresses on DH+/RIO; verify scan lists and data mapping before cutover.
Routine care – Periodically back up configuration, review diagnostics for retries/errors, inspect connectors, and apply firmware updates during planned downtime.
Safety – De-energize the panel before wiring changes; follow lockout/tagout and ESD practices.
CE, UL/cUL, and RoHS compliance are typically supported for this platform.
Manufacturer hardware warranty is commonly 1 year; we provide a 365‑day warranty with orders.
24 VDC DIN-rail power supply sized for gateway and network accessories.
Belden 9463 or equivalent blue-hose cable for DH+/RIO segments.
Appropriate 3‑pin plug/terminal for the DH+/RIO port and proper termination resistors.
Industrial Ethernet switch (managed) for VLAN/QoS where controller traffic requires it.
If you’re planning a phased PLC‑5 or SLC migration, the AN‑X2‑AB‑DHRIO seems to be one of the safer paths to keep production stable while moving to EtherNet/IP. From my experience, a quick bench test of scan lists and data mapping pays off before the on‑site switchover.
