Help CenterALSTOM MVAJ53H1LB0856A – Heavy‑Duty Auxiliary Tripping Relay for Substation and Industrial Protection
Related Products
-
ALSTOM MVAW11B1AB9007A – Auxiliary Protection Relay for Trip/Interlock Duties in Power SystemsUS$ 3660.00MOQ: 1 Combo -
ALSTOM MVAX31C1DF0754A – Rack‑mount Control Module for Alstom Legacy Automation and Protection SystemsUS$ 3660.00MOQ: 1 Combo
-
ALSTOM MVAX12B1DA0753A – Plug‑in I/O Module for MVAX Automation and Protection SystemsUS$ 3660.00MOQ: 1 Combo
-
ALSTOM MVTT14B1BA0773C – Plug‑In Turbine Control Module for Legacy ALSTOM RacksUS$ 3660.00MOQ: 1 Combo
-
ALSTOM MVTU11K1CD0751G – Voltage Transducer/Measurement Module for Protection and Control SystemsUS$ 3660.00MOQ: 1 Combo
Warranty: 365 days
Lead time: typically 1 week if in stock; no more than 1 month at the latest
Payment: 50% advance payment; full payment prior to delivery
Express options: FedEx, UPS, DHL
Pre‑shipment checks: model/coil rating verification against nameplate, contact condition, and functional pickup/reset test
Attracted‑armature tripping design – Built for dependable trip duty in protection schemes with fast operate characteristics.
Hand‑reset latch with target – Mechanical flag gives a clear, non‑volatile indication; hand reset avoids inadvertent re‑energization.
High‑capacity contacts – Suited for circuit breaker trip coils; typically used to multiply outputs from protection relays.
Low burden on protection elements – Coil burden is kept reasonable so upstream protection contacts aren’t overstressed.
Draw‑out, panel‑mount case – Makes installation and replacement straightforward in existing relay panels.
No communication dependency – Purely electromechanical; immune to network or firmware issues.
Legacy compatibility – Often drop‑in compatible with existing GEC/ALSTOM installations, which typically keeps retrofit costs down.
| Brand / Model | ALSTOM MVAJ53H1LB0856A (MVAJ series tripping relay) |
| HS Code | 8536.49 (Relays, other than for ≤60 V) |
| Function | Auxiliary/tripping relay with hand‑reset latch and mechanical indication |
| Power Requirements | DC coil (variant‑dependent; commonly supplied in 110 V DC or 220/250 V DC). We verify the exact coil rating on the nameplate before shipment. |
| Signal I/O Types | Mechanical trip contacts for breaker coils and interlocking (NO/NC per variant); coil input from protection device trip output |
| Operate / Reset | Fast operate (typically single‑digit milliseconds under rated voltage); hand‑reset latch with visible flag |
| Communication Interfaces | None (electromechanical device) |
| Installation Method | Panel flush‑mount, draw‑out relay case with screw terminals; front hand reset and flag |
| Operating Temperature | Typically −10 °C to +55 °C for this series |
| Dimensions & Weight | Standard ALSTOM draw‑out relay case (commonly the E‑series footprint used in protection panels); weight is typically in the 1.5–2.0 kg range depending on element count. |
You might notice that the MVAJ53 variants show up all over the grid. Typical uses include:
Substation protection tripping – interposing between distance, differential, or O/C relays and CB trip coils
Trip multiplication and interlocking – distributing a single protection output to multiple breakers
Breaker fail and lockout schemes – where a latched, hand‑reset action is preferred
Power plants and heavy industry – turbine‑generator and transformer protection auxiliaries
Oil & gas, mining, metals – harsh environments where a simple, visible, and testable trip element is valued
“We swapped in MVAJ relays during a feeder panel refurbishment. The hand reset target makes post‑event checks quicker, and the draw‑out case saved us time on replacement.” – Protection supervisor, utility client
Reliability – A simple electromechanical mechanism that, in many cases, outlasts the surrounding equipment with routine maintenance.
Compatibility – Fits established ALSTOM/GEC panel standards, reducing retrofit effort and wiring changes.
Cost Control – Avoids costly redesigns of protection schemes; keeps critical spares standardized across bays.
Support – We check coil voltage and contact configuration against your scheme drawings before shipment to avoid onsite surprises.
For panel installations, I typically recommend a clean, ventilated relay cubicle with stable DC supply and proper segregation of trip wiring.
Mounting – Flush/panel mount in a standard draw‑out case. Ensure adequate front clearance for hand reset and flag visibility.
Wiring – Use ferruled conductors, tighten to specified torque, and keep trip circuits segregated from CT and communication circuits. Verify polarity and DC supply rating.
Environment – Keep within the typical −10…+55 °C range; avoid vibration and conductive dust. Provide modest ventilation if grouped densely.
Routine checks – Quarterly or semi‑annual: contact resistance check, functional pickup/reset test, flag and hand‑reset mechanism inspection, and cleaning of terminals.
Documentation – Label coil voltage and contact assignment on the panel door; it saves time during fault investigations.
Conforms to IEC 60255 practices for protection relays (series standard)
CE marking typically applied for EU deliveries
Manufactured under ISO 9001 quality systems (manufacturer)
Warranty: 365 days from delivery
ALSTOM MVAA series – auxiliary relays for signaling and interlocking
Lockout/86 device (e.g., ALSTOM lockout relay variants) – for system lock/trip retention
Trip circuit supervision relays – to monitor trip coil health and circuit continuity
Test plugs and links for draw‑out cases – to simplify commissioning and routine testing
If you share your coil voltage and contact requirements, we’ll confirm the MVAJ53H1LB0856A build against your scheme and ship the matching unit with test results attached.
