MZF-H series UV inclined laser marking machine
PRODUCT DESCRIPTION TI O N
The MZF-H Series Tilt-Surface Smart Machine is a desktop UV laser marking system specifically engineered for high-precision applications with broad adaptability. Its compact design and flexible configuration meet diverse operational requirements. Developed using 355nm ultraviolet (UV) laser technology, the equipment features advanced material compatibility through optimized coating technologies that maximize UV absorption efficiency. The ultra-sharp focused beam creates minimal thermal impact zones, enabling precise ultra-fine marking across various substrates with exceptional precision.
Ultraviolet inclined laser marking machine is used in the high-end market of ultra-fine processing, precision cutting and micro-processed, mainly used for the marking and surface treatment of various glass, liquid crystal screen, textiles, thin ceramic, semiconductor silicon wafer, IC chip, sapphire, polymer film and other materials.
The MZF-H series employs Jupet Laser 's pulsed ultraviolet (PUV) laser technology, delivering exceptional beam quality and perfectly shaped light spots. Featuring an integrated design that combines optical systems with external drive circuits, this series boasts exceptional anti-interference capabilities. The upgraded fully sealed structure effectively prevents external dust contamination, ensuring optimal performance in industrial environments.
Note: Laser marking machines with different power (W) are different in terms of marking accuracy, depth, speed, color depth and service life. Please communicate with the sales personnel of the code to choose a solution according to the marking products and requirements.
100% portable
● Compact design, the whole machine is small and portable, and the column light path can be disassembled and assembled at will
● Hidden mouse and keyboard design, one-click pop-up, flexible use and space saving
● Optional transport box, thick shockproof, hand lever design, more convenient transportation
Cost-effective
● The whole machine is small, flexible, convenient, powerful and not limited by space
● It can run efficiently for 24 hours continuously to improve production efficiency and save cost
● Stable performance, long service life, one-year warranty and lifetime maintenance
High-quality light source
● Using advanced fiber laser, the output beam quality is good, the reliability is high
● No consumables and maintenance-free, working life is about 100,000 hours
● It can be flexibly applied to metallic materials and some non-metallic materials
SMALL AND FLEXIBLE, DIVERSIFIED APPLICATIONS
Desktop optical fiber marking equipment, a special product specially developed for the needs of simple, compact, flexible and convenient equipment
COMPACT AND STURDY STRUCTURE, ONE YEAR WARRANTY
The overall integrated cabinet design, novel style, compact and firm structure, stable performance and guaranteed, we promise that the whole machine is guaranteed for one year.
HIDDEN MOUSE AND KEYBOARD
Hidden mouse and keyboard designed for easy portability, one-click pop-up, saving space, wireless mouse, no cable
constraints, more flexible use .
COLUMN BEAM PATH CAN BE FLEXIBLY DISASSEMBLED
The beam path and the column can be flexibly disassembled, the marking position can be arranged as you want, the storage is more convenient; the disassembly and assembly are simple, it only need to loosen the screws to disassemble and assemble
