Tensile Strength Compression Tear Tester Universal Material Tensile Testing Machine

Tensile Strength Compression Tear Tester Universal Material Tensile Testing Machine photo-1
Tensile Strength Compression Tear Tester Universal Material Tensile Testing Machine photo-2
Tensile Strength Compression Tear Tester Universal Material Tensile Testing Machine photo-3
Tensile Strength Compression Tear Tester Universal Material Tensile Testing Machine photo-4
Tensile Strength Compression Tear Tester Universal Material Tensile Testing Machine photo-5
US$ 4800 1 - 4 Set
US$ 4400 ≥5 Set
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2010
Factory Size:
1,000-3,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao,shanghai,tianjin
Delivery Detail:
15 days

The machine adopts a double-space door structure, the upper space is stretched, and the lower space is compressed and bent. The beam is stepless lifting. The transmission part adopts circular arc synchronous toothed belt, screw pair transmission, stable transmission and low noise. The specially designed synchronous toothed belt deceleration system and precision ball screw pair drive the moving beam of the testing machine to realize a backlash-free transmission.

Specification

Model
WDW-100KN
Testing machine type
Computer control and dual-column type
Capacity
100kN(10T)
Measuring range
2%—100%FS
Resolution of displacement
0.1 mm
Range of displacement speed control
0.1-500mm/min
Test space width
≥380mm(Can be customized)
Distance between beam and workbench
650mm(Can be customized)
Dimensions
760*420*1850 mm
Power supply
220V,50Hz(Can be customized)
Total weight
About 450 kg
