Spirometer calibration syringe
Product Introduction
Pulmonary function meter calibrator is an instrument used to calibrate pulmonary function test equipment (such as respiratory flow meters,
volumetric meters, etc.). It is used to ensure the accuracy and reliability of lung function instruments to ensure the accuracy and comparability
of test results. The accuracy and reliability of the pulmonary function test equipment can be ensured by using the pulmonary function meter
calibrator. Regular calibration can keep the performance of the instrument stable and provide accurate and comparable lung function test
results to support clinical diagnosis, research and treatment decisions. The pulmonary function instrument calibration device is mainly used
for the performance test of the pulmonary function instrument, using the basic principle of respiratory movement, simulating the basic
movement pattern of the lung, and inputting standard gas to the pulmonary function instrument. In line with the JJF1213-2008 "pulmonary
function instrument calibration specification", to meet the measurement and calibration institutions, biological laboratories, instrument
manufacturers of domestic and foreign pulmonary function instrument testing and calibration requirements.
Product Features
Small size, light weight, easy to carry
touch screen control, simple and convenient operation, beautiful appearance
The instrument is stable and reliable and does not require special maintenance
is made of metal material, strong and durable
connection is convenient and fast, and verification saves time and effort
better software for automatic generation of calibration reports
Product Specifications
| Product Name | CY1213 |
| Exhaled Gas Volume | (0~10)L |
| Cccuracy | ± 0.5%(greater than or equal to 2L),± 20mL (less than 2L) |
| Output gas flow | can provide waveform A output 100L/min,150L/min,200L/min,300L/min,450L/min,600L/min,720L/min and other gas flow |
| Outgoing Peak Flow | (1~14)L/s; Accuracy: ± 2.0; Repeatability better than ± 1% |
| Peak expiratory floW in 120ms | can produce a peak expiratory flow of 720L/min in 120ms |
| Waveform A and Waveform B | can generate 26 PEF test standard waveforms recommend by the American Thoracic Association and waveforms A and B recommend in YY/T 1438-2016 |
| B waveform | RT is 24ms ~ 36ms,DT is 12ms ~ 18ms;A waveform, RT is 120ms ~ 140ms,DT is 100ms ~ 120ms |
| PEF Standard Waveform |
is available and also provides 24 standard waveforms of FVC specified by the American Thoracic Association, as well as VC and MVV waveforms.detection that satisfies these four parameters |
| Airway pressure | (0~20)kPa, accuracy: better than 0.4 |
| Host weight | 10.35kg,L*W*H:46*27*20.5cm |
| Breathing Waveform Generator Weight | 31.4kg,L*W*H:75*35*34cm |
