The ABB S-113H, ordering code 3BHB018008R0003, is a board-level gate/interface unit designed for ABB medium-voltage converter stacks, typically seen in PCS6000 and ACS 6000 platforms. From my experience, it’s the form-fit-function spare you reach for when you need reliable switching control and safe isolation around IGCT-based power modules. It tends to drop straight in, restoring phase control stability with minimal re-commissioning.
Form-fit replacement – Built to match ABB’s 3BHB018008R0003 footprint and connectors, typically enabling quick swap without cabinet rework.
Fiber-optic isolation – Optical gate/fault links help reduce noise susceptibility in high dv/dt MV drive environments.
Integrated protection feedback – Status and interlock signals allow the host controller to react fast to gate/stack conditions.
Robust construction for MV drives – Designed for use inside ABB converter enclosures where thermal and electrical stresses are higher than low-voltage drives.
Service-friendly – Clearly keyed connectors and guided mounting points typically shorten maintenance windows.
Compatibility with ABB toolchain – Works within the native diagnostics of PCS/ACS 6000 systems for commissioning and health checks.
| Brand / Model | ABB S-113H (Ordering code: 3BHB018008R0003) |
| Function | Gate/interface unit for IGCT-based power stacks in PCS6000 / ACS 6000 converters |
| Power Requirements | Typically supplied from the host drive’s low-voltage rail (nominal 24 VDC within enclosure) |
| Signal I/O Types | Fiber-optic gate triggers and returns; low-voltage status/interlock lines to controller |
| Communication Interfaces | Internal to ABB drive system; diagnostics via host converter tools |
| Installation Method | Chassis-mounted within the converter power stack; fixed with standoffs and keyed connectors |
| Compatible Systems | PCS6000 / ACS 6000 families using S-113H-series gate units (verify against your stack BOM) |
You’ll typically find the S-113H inside ABB medium-voltage drives used in heavy industries where uptime matters: mining hoists, rolling mills, test benches, oil & gas compressors, and large pump/fan applications. It also shows up in PCS6000-based converters for energy and process applications, where reliable IGCT gate management is non-negotiable.
One maintenance manager told us they kept two S-113H units on the shelf during a mill upgrade—swapping one in took under an hour, and the drive came back online without retuning the entire stack. That seems to be the typical experience when the BOM match is confirmed beforehand.
Advantages & ValueReduced downtime – Form-fit design and predictable behavior shorten outage windows during planned or corrective maintenance.
System integrity – Proper optical isolation and ABB-native signaling help keep nuisance trips low in noisy MV cabinets.
Lifecycle alignment – Matches ABB service documentation and parts lists, making audits and spares planning more straightforward.
Total cost control – Stable mean time between failure in many cases means fewer interventions and less re-commissioning time.
Environment – Install inside the designated converter cabinet; ensure adequate ventilation and that ambient conditions match the host drive’s rating.
Safety – Follow LOTO; discharge DC link; observe ESD precautions; do not touch fiber ends or IGCT interfaces when energized.
Wiring & optics – Verify connector keying; respect fiber bend radius; clean optical connectors with approved tools to maintain signal integrity.
Commissioning – After replacement, run the drive’s built-in diagnostics; check interlock status and gate-firing readiness before enabling power.
Routine care – Quarterly visual inspection for dust and connector looseness; keep fibers clean; apply firmware or parameter updates as specified by ABB for the host system.
Manufacturing standards – Produced under ABB quality systems (ISO 9001).
Compliance – Intended for use within CE/UL-certified converter systems; RoHS alignment typically follows the host drive’s conformity.
Warranty – ABB standard spare-part warranty applies (often 12 months from supply, depending on channel and region). Please confirm for your order.
