Premium Grade 5 Titanium Sheet - 0.1mm to 2.0mm Thickness
- TIANJIN
- T/T
- 15 days
You May Like
-
High-Performance Inconel 718 Alloy Plate for Extreme Conditions
-
Hot Rolled 3mm 5mm 10mm Thickness AISI 316L Stainless Steel Plate
-
304 304L 316 316L Mirror Polished Stainless Steel Sheet Plate
-
Full Sizes AISI Metal Plate SS304L 316L Hot/Cold Rolled 2b Ba 8K Mirror No. 1 Polished Embossed Hairline Checkered Stainless Steel Sheet/Plate
-
Wholesale Corrosion Resistant Galvanized Steel Sheet/Plate Price for Construction
-
Zirconium Alloy Plates, Cold-Rolled Zirconium Plates, Hot-Rolled Zirconium Plates, Polished Zirconium Plates, Customizable Zirconium Plate
Product Details
| Material | Other | Shape | Other | |
| Color | Titanium Gold | Surface Treatment | Other, Coated | |
| Specification | Thickness: 12mm | Origin | CHINA |
Product Description
stainless steel roll
Item Name | Titanium plate |
Type | GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6, TC4, TC6, TC11, TC17, TC18 |
Standard | ASTM B265, AMS4911, AMS4911H, GB/T3621-2007 |
Specification | Hot Rolling: Length 1000-4000mm,Width 400-3000mm,Thickness 4.1-60mm Cold Rolling :Length 1000-3000mm,Width 400-1500mm,Thickness 0.3-3.0mm |
Certificate | ISO 9001:2008 |
Supply Ability | 10 Tons per Month |
Delivery | Within 5~30 days |
Grade | Grade 1: Pure Titanium, relatively low strength and high ductility. Grade 2: The pure titanium most used. The best combination of strength, weldability. Grade 3: High strength Titanium, used for Matrix-plates in shell and tube heat exchangers. Grade 5: The most manufactured titanium alloy. Exceedingly high strength. high heat resistance. Grade 7: Superior corrosion resistance in reducing and oxidizing environments. Grade 9: Very high strength and corrosion resistance. Grade 12: Better heat resistance than pure Titanium. Applications as for Grade 7 and Grade 11. Grade 23: Titanium-6Aluminum- 4Vanadium ELI. Alloy for surgical implant application. |
Application | Metallurgy, electronics, medical, chemical, petroleum, aerospace, and others. |
| 1.Chemical requirements | |||||||||||
| Grade | N(≤) | C(≤) | H(≤) | Fe(≤) | O(≤) | Al(≤) | V(≤) | Pd(≤) | Mo(≤) | Ni(≤) | Ti |
| GR1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | bal |
| GR2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | bal |
| GR3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | bal |
| GR4 | 0.05 | 0.08 | 0.015 | 0.2 | 0.4 | / | / | / | / | / | bal |
| GR5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| GR7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| GR9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
| GR12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
| GR23 | 0.05 | 0.08 | 0.012 | 0.25 | 0.13 | 5.5~6.5 | 3.5~4.5 | bal | |||
| 2.Tensile requirements | |||||
| Grade | Tensil strength(≥) | Yeild strength(≥)) | Elongation(≥)%) | ||
| ksi | Mpa | ksi | Mpa | ||
| GR1 | 35 | 240 | 20 | 138 | 24 |
| GR2 | 50 | 345 | 40 | 275 | 20 |
| GR3 | 65 | 450 | 55 | 380 | 18 |
| GR4 | 80 | 550 | 70 | 483 | 15 |
| GR5 | 130 | 895 | 120 | 828 | 10 |
| GR7 | 50 | 345 | 40 | 275 | 20 |
| GR9 | 90 | 620 | 70 | 483 | 15 |
| GR12 | 70 | 483 | 20 | 345 | 18 |
| GR23 | 120 | 828 | 110 | 760 | 10 |
Application field of titanium plateAerospace: Titanium plates are widely used in the aerospace field, such as the manufacture of aircraft structural parts, engine parts, spacecraft shells and so on.
Chemical industry: Because titanium plate has excellent corrosion resistance, it is widely used in chemical equipment, pipelines, storage tanks and other fields.
Medical field: Titanium plate is widely used in medical devices, artificial joints, dental implants, etc., because of its good biocompatibility, it will not reject the human body.
Energy field: Titanium plates are used in the manufacture of nuclear reactor vessels in nuclear power plants, pipelines and equipment in offshore oil platforms.
Automotive industry: Titanium plates are used in automotive manufacturing to reduce body mass and improve fuel efficiency and power performance.
Sporting goods: such as golf clubs, bicycle frames, etc., using the lightweight and high-strength characteristics of titanium plates to improve product performance.

Zhongzheng Stainless Steel Co., Ltd. was established in 2018 with aregistered capital of 20 million yuan. lt is a manufacturing company thatintegrates the production of special materials, manufacturing andprocessing, sales, and technology development. The company covers anarea of 2,000 square meters and has 200 employees. it has built worldclass stainless steel seamless pipe (hot piercing, cold drawing, cold rollingproduction lines, precision steel pipe production lines, and large, mediumand small-sized welded pipe production lines. The company has beencommitted to providing high performance, high precision, hightemperature-resistant, high pressure-resistant, and corrosion-resistantsolutions and technical services for industrial equipment pipeline systems.The company specializes in producing a series of steel pipes, pipe fittingsflanges, etc., such as high-temperature (nickel-based) alloys, austeniticduplex steel, urea grade stainless steel, super stainless steel, etc. Thecompany is equipped with an annual production capacity of 5,000 tons ofstainless steel seamless pipe production line, 7,000 tons of welded pipeproduction line, and 500 tons of pipe fittings production line, etc. lt canoroduce stainless steel seamless pipes with diameters ranging from Φ6 toΦ762 and wall thicknesses ranging from 0.5 to 70 mm, stainless steelwelded pipes with diameters ranging from Φ15 to Φ2200 and wallthicknesses ranging from 0.5 to 80 mm, pipe fittings, and various stainlesssteel ingots, round steel, rough pipes, etc., according to customerrequirements and in accordance with standards such as GB, ASTM, etc.
Company Profile
Zhongzheng Stainless Steel Co., Ltd. is a China-based manufacturer specializing in R&D, production, and distribution of stainless steel products. Established in the early 2000s, it serves industries including construction, machinery, food/medical equipment, and energy with precision tubes, sheets, profiles, and custom components.
