Parker High-Strength Cast Low Noise High Efficiency
Plunger Pump PAVC10038R4222
Competitive Brands
Rexroth, Hagglunds, Aventics, Danfoss, Parker, Moog, Sunhydraforce, Hawe, Vickers, Siemens, Skf and other European and American brands.
Products
Plunger pump, Solenoid valve, Gear pump, Vane pump, Direction valve, Servo valve, Proportional valve, Servo motor
Details
| Brand | Parker |
| Model | PAVC10038R4222 |
| Color | Grey |
| Material | Cast Iron |
| Power Source | Electric |
| Place Of Origin | America |
Advantages
1. High-strength cast iron housing, impact-resistant and fatigue-resistant, capable of withstanding continuous pressure up to 207 bar, resulting in a longer service life.
2. Built-in booster, maximum speed 2600 RPM, ensuring high self-priming capability and reducing dependence on tank level.
3. 9-pump pre-compression volume technology, minimizing flow pulsation and reducing noise by an average of 3–5 dB(A), resulting in smoother system operation.
4. Two-stage housing + cartridge control valve, allowing for replacement of compensators or load-sensitive valves without disassembling the pump body during maintenance, reducing downtime by over 50%.
5. Through-shaft design, can be directly coupled to gear pumps or connected in series with other PAVCs as a multi-unit pump, saving installation space and transmission costs.
6. Bronze composite distribution plate is replaceable on-site, maintaining full rated pressure for flame-retardant liquids such as water-glycol and phosphate esters, meeting explosion-proof and high-temperature environment requirements. 7. Comprehensive Control Methods: Pressure compensation, remote compensation, load sensitivity, power limiting, electro-hydraulic proportional flow/pressure, low-pressure standby, facilitating OEMs to achieve energy saving and multi-actuator composite actions.
Application Areas
Metallurgical Rolling mills and continuous casting lines
High-pressure, high-flow continuous roll adjustment and sequential control.
Forging/Injection molding machines
With load sensitivity or power limiting, achieving fast descent-slow pressing-return multi-speed curves, saving 10-15% energy.
Port and marine deck machinery
Through-shaft tandem pump sets, reducing the number of drive shafts and improving reliability.
Oilfield Cementing And Fracturing trucks
Full rated pressure under water-glycol media, meeting explosion-proof and low-temperature start-up requirements.
Mobile Machinery
Compact through-shaft structure for direct connection to engine PTO, saving space.
