MG376 POLISHING METAL MACHINE
This is a semi-automatic plane wire drawing machine, suitable for drawing all kinds of stainless steel products.
Because of the changes in the style and shape of stainless steel products and plate thickness, may lead to the workpiece drawing surface bearing capacity is different, so it needs a certain flexibility and space.
For the thickness of stainless steel products sheet changes, in order to adapt to a wider range, but also for the effect of easy to achieve, the drawing wheel is specially equipped with a transmission, to change speed to match the plate support force and deformation, in order to ensure a more reasonable control of the drawing polishing effect. For example: thin sheet with slow speed, smooth speed, not easy to appear popping lines. Fast drawing of thick sheet metal, high efficiency.
Grain thickness and luster effect can be achieved by changing the thickness and granularity of the drawing polishing wheel.
For the product height change and the wear of the drawing wheel, the platform needs to go up and down to match. Operation mode for electric one-key lifting, by the motor with each reducer with chain pull lifting, strong bearing capacity, and up and down lifting will not be stuck.
The working head part can work up and down elastic, the head up and down flexible movement, for the drawing and polishing products surface flatness tolerance is very good, also has the possibility to adapt to other shapes of products.
The shaft core of the wire drawing polishing wheel is made according to the technological requirements of the hardware mold.First, it is processed by heat treatment, then straightened, and then the shaft shape is drawn out. In this way, the shaft hardness of the processing is better and the wear resistance is more.
The belt driving the wire drawing wheel is a special belt for the car, wear-resistant and heat-resistant durable, not easy to
break.
Because the equipment has track bearing, fixed track movement, so only suitable for drawing long straight wire, uniform and clear effect, drawing lines stable, operation does not need technology, is the best choice to replace portable polishing machine.
