Factory Round Mirror Surface Ss 304 Stainless Steel Pipe for Furniture

Factory Round Mirror Surface Ss 304 Stainless Steel Pipe for Furniture photo-1
Factory Round Mirror Surface Ss 304 Stainless Steel Pipe for Furniture photo-2
Factory Round Mirror Surface Ss 304 Stainless Steel Pipe for Furniture photo-3
Factory Round Mirror Surface Ss 304 Stainless Steel Pipe for Furniture photo-4
Factory Round Mirror Surface Ss 304 Stainless Steel Pipe for Furniture photo-5
US$ 800 - 1100 MOQ: 1 Ton
Key Specifications
Get Latest Price
Type:
Seamless
Surface Treatment:
Other
Usage:
Pipeline Transport, Boiler Pipe, Oil/Gas Drilling, Machinery Industry, Chemical Industry, Mining, Special Purpose
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI/TIANJIN/XIAMEN
Delivery Detail:
8 days
Type Seamless
Surface Treatment Other
Usage Pipeline Transport, Boiler Pipe, Oil/Gas Drilling, Machinery Industry, Chemical Industry, Mining, Special Purpose
Material Stainless steel
Section Shape Round
Delivery Time 8-14 days
Model Number 304 316 310 904 2205 2507
Processing Service Bending, Welding, Decoiling, Punching, C
Specification 0D 3in under




ASTM A790 Duplex Stainless Steel Pipe-Saso Approved Falaj Irrigation Lines for Neom Smart City Solar Farms


Name ASTM A790 Duplex Stainless Steel Pipe-SASO Approved Falaj Irrigation Lines for NEOM Smart City Solar Farms
Standard ASTM, GB, JIS, DIN, EN, AISI
Material Grade TP304 TP304L TP316 TP316L TP347 TP347H TP321 TP321H TP310 TP310S
TP410 TP410S TP403
S31803/S32205 S32750 S32760
Outer Diameter Seamless Pipe: 4mm-812.80mm
Welded Pipe: single slit(Φ8mm-Φ630mm); girth(Φ630mm-Φ3000mm)
Thickness Seamless Pipe: 0.5mm - 60mm
Welded Pipe: single slit(0.5mm-25mm);girth(3mm-45mm)
Length 5.8-6.1 m or as customers' request
Tolerance Acording to the Standard.
Surface 180G, 320G, 400G Satin / Hairline
400G, 500G, 600G or 800G Mirror finish
Test UT, ET, HT, RT, ect, and others according to the standard, or as the requests of the customers
Certificate ISO9001-2008, ASME, PED
Delivery Time 30-60Days, Depends on quantity



Product Name  Stainless Steel Pipe,   Stainless Steel Tube
Specification OD: Seamless ( 6.0-1000mm), Welded (50-2500mm). Customized sizes are accepted
Thickness  0.1-200mm
Length 1000-12000mm
Standard  ASME, ASTM, EN, BS, GB, DIN, JIS, et
Material  304, 304L, 310S, 310, 309, 309S, 314, 316, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, etc.
Finish  2B, 2D, BA, NO.1, NO.4, NO.8,  8K, mirror,  checkered,  hair line,  sandblast,  brush,  etc
Brand Name  TISCO, Baosteel, LISCO, JISCO
Place of Origin  China
Port of Loading  TIANJIN, GUANGZHOU, NIINGBO, SHANGHAI or as required
Terms of Delivery  FOB, CFR, CIF, CNF, Ex-Work
Terms of Payment  TT/ LC, Accept other payment methods
Delivery time  Within 3-15 days or as your requirement
Package  Standard Export Seaworthy Package, or as required.
MTC  Mill Test Certificate is supplied with shipment, Third Part Inspection is acceptable
Certificate  ISO 9001 BV SGS,etc
Stock  Ready in stocks



Chemical Composition (%)
Grade C Mn Si Cr Ni P S Mo
201 ≤0.15 5.5-7.5 ≤0.75 16.0-18.0 3.5-5.5 ≤0.06 ≤ 0.03
304 ≤0.08 ≤2.0 ≤1.0 18.0-20.0 8.0-10.5 ≤0.045 ≤ 0.03
304L ≤0.03 ≤2.0 ≤1.0 18.0-20.0 9.0-13.0 ≤0.045 ≤ 0.03
304H 0.04-0.10 ≤2.0 ≤0.75 18.0-20.0 8.0-10.5 ≤0.045 ≤ 0.03
304N ≤0.08 ≤2.0 ≤0.75 18.0-20.0 8.0-10.5 ≤0.045 ≤ 0.03
305 ≤0.12 ≤2.0 ≤0.75 17.0-19.0 10.5-13.0 ≤0.045 ≤ 0.03
309 ≤0.20 ≤2.0 ≤0.75 22.0-24.0 12.0-15.0 ≤0.045 ≤ 0.03
309S ≤0.08 ≤2.0 ≤0.75 22.0-24.0 12.0-15.0 ≤0.045 ≤ 0.03
310S ≤0.08 ≤2.0 ≤1.5 24.0-26.0 19.0-22.0 ≤0.045 ≤ 0.03
314 ≤0.25 ≤2.0 1.5-3.0 23.0-26.0 19.0-22.0 ≤0.045 ≤ 0.03
316 ≤0.08 ≤2.0 ≤0.75 16.0-18.0 10.0-14.0 ≤0.045 ≤ 0.03 Mo 2.0-3.0
316L ≤0.03 ≤2.0 ≤0.75 16.0-18.0 10.0-14.0 ≤0.045 ≤ 0.03 Mo 2.0-3.0
316N ≤0.08 ≤2.0 ≤0.75 16.0-18.0 10.0-14.0 ≤0.045 ≤ 0.03 Mo 2.0-3.0
316Ti ≤0.08 ≤2.0 ≤1.0 16.0-18.0 10.0-14.0 ≤0.045 ≤ 0.03 Mo 2.0-3.0
Ti   0.2-0.7
317L ≤0.03 ≤2.0 ≤0.75 18.0-20.0 11.0-15.0 ≤0.045 ≤ 0.03
321 ≤0.08 ≤2.0 ≤0.75 17.0-19.0 9.0-12.0 ≤0.045 ≤ 0.03
321H 0.04-0.10 ≤2.0 ≤0.75 17.0-19.0 9.0-12.0 ≤0.045 ≤ 0.03
329 ≤0.08 ≤1.00 ≤0.75 23.0-28.0 2.0-5.0 ≤0.04 ≤0.03
347H 0.4-0.10 ≤2.0 ≤0.75 17.0-19.0 9.0-13.0 ≤0.045 ≤ 0.03
409 ≤0.08 ≤1.0 ≤1.0 10.5-11.75 0.50 ≤0.045 ≤ 0.03
410 ≤0.15 ≤1.0 ≤1.0 11.5-13.5 0.75 ≤0.04 ≤0.03
430 ≤0.12 ≤1.0 ≤1.0 16.0-18.0 0.75 ≤0.04 ≤0.03
17-4PH ≤0.07 ≤1.0 ≤1.0 15.5-17.5 3.0-5.0 ≤0.04 ≤0.03
17-7PH ≤0.09 ≤1.0 ≤1.0 16.0-18.0 6.5-7.75 ≤0.04 ≤0.03 AL 0.75-1.5
904L ≤0.02 ≤2.0 ≤1.0 19.0-23.0 23.0-28.0 ≤0.045 ≤0.035
2205  ≤0.03 ≤2.0 ≤1.0 22.0-23.0 4.5-6.5 ≤0.03 ≤0.02
2507 ≤0.03 ≤1.0 ≤0.8 24.0-26.0 6.0-8.0 ≤0.035 ≤0.02



Seamless Stainless-Steel Pipes:

Size:1/8” to 24” (10.3mm to 610mm)

Schedules: 10s, 20, 40s, 40, 60, 80s, 80, 100, 120, 140, 160, XXH

Wall Thickness: 1mm to 60mm
Grade Specification
Stainless 304/304L, 304/304H ASTM A312/SA312
Stainless 309S ASTM A312/SA312
Stainless 310S ASTM A312/SA312
Stainless 316/316L, 316/316H ASTM A312/SA312
Stainless 317/317L ASTM A312/SA312
Stainless 321/321H ASTM A312/SA312
Stainless 347/347H ASTM A312/SA312



Welded stainless steel pipe

Size:1/8” to 36” (10.3mm to 914mm)

Schedules: 5s, 10s, 20, 40s, 40, 60, 80s, 80

Wall Thickness: 1mm to 12.7mm
Grade Specification
Stainless 304/304L, 304/304H A/SA312
Stainless 316/316L. 316/316H A/SA312
Stainless 317/317L A/SA312
Stainless 321/321H A/SA312
Stainless 347/347H A/SA312
Shape: RoundLength: Single random length/ Double random length or as customer’s actual request

Referenced Documents:

ASTM Referenced Standards

A262 Practices for Detecting Susceptibility to Intergranular Attack in Austenitic Stainless Steels

A370 Test Methods and Definitions for Mechanical Testing of Steel Products

A941 Terminology Relating to Steel, Stainless Steel, Related Alloys, and Ferroalloys

A999/A999M Specification for General Requirements for Alloy and Stainless-Steel Pipes

A1016/A1016M Specification for General Requirements for Ferritic Alloy Steel, Austenitic Alloy Steel, and Stainless-Steel Tubes

E112 Test Methods for Determining Average Grain Size

E381 Method of Macroetch Testing Steel Bars, Billets, Blooms, and Forgings

E527 Practice for Numbering Metals and Alloys in the Unified Numbering System (UNS)

Chemical Composition:

Grade UNS
Design
Composition, %
C Mn P S Si Cr Ni Mb Ti Nb N Cu Ce B Al
TP304 S30400 0.08 2 0.045 0.03 1 18.0–20 8.0–11 . . . . . . . . . . . . . . . . . .

TP304L S30403 0.035 2 0.045 0.03 1 18.0–20 8.0–13 . . . . . . . . . . . . . . . . . .

TP304H S30409 0.04 – 0.1 2 0.045 0.03 1 18.0–20 8.0–11 . . . . . . . . . . . . . . . . . .

TP310S S31008 0.08 2 0.045 0.03 1 24.0- 26 19.0- 22 0.8 . . . . . . . . . . . . . . .

TP310H S31009 0.04 – 0.1 2 0.045 0.03 1 24.0–26 19.0–22 . . . . . . . . . . . .
. . .

TP310H S31035 0.04 – 0.1 0.6 0.025 0.015 0.4 21.5–23.5 23.5–26.5 . . . . . . 0.40- 0.6 0.20- 0.3 2.5- 3.5 . . . 0.002- 0.008
TP316 S31600 0.08 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .

TP316L S31603 0.035 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .

TP316H S31609 0.04 – 0.1 2 0.045 0.03 1 16.0–18 10.0–14 2.00–3 . . . . . . . . . . . . . . .

TP317 S31700 0.08 2 0.045 0.03 1 18.0–20 11.0–15 3.0–4 . . . . . . . . . . . . . . .

TP317L S31703 0.035 2 0.045 0.03 1 18.0–20 11.0–15 3.0–4 . . . . . . . . . . . . . . .

TP321 S32100 0.08 2 0.045 0.03 1 17.0–19 9.0–12 . . . Ti 5 × (C+N) min, 0.70 max . . . 0.1 . . . . . .

TP321H S32109 0.04 – 0.1 2 0.045 0.03 1 17.0–19 9.0–12 . . . 4(C+N) min; 0.70 max . . . 0.1 . . . . . .

TP321H S32654 0.02 2.0-4 0.03 0.005 0.5 24.0–25 21.0–23 7.0-8 . . . . . . 0.45- 0.55 0.30-0.6 . . .

TP321H S33228 0.04 – 0.08 1 0.02 0.015 0.3 26.0–28 31.0–33 . . . . . . 0.60- 1 . . . . . . 0.05 – 0.1
0.025
TP321H S34565 0.03 5.0-7 0.03 0.01 1 23.0–25 16.0–18 4.0-5 . . . 0.1 0.40- 0.6 . . . . . .

TP347 S34700 0.08 2 0.045 0.03 1 17.0–19 9.0–13 . . . . . . See Spec . . . . . . . . .

TP347H S34709 0.04 – 0.1 2 0.045 0.03 1 17.0–19 9.0–13 . . . . . . See Spec . . . . . . . . .

Alloy 20 N08020 0.07 2 0.045 0.035 1 19.0–21 32.0–38 2.0–3 . . . See Spec . . . 3.0– 4 . . . . . . . . .
Alloy 20 N08367 0.03 2 0.04 0.03 1 20.0–22 23.5–25.5 6.0–7 . . . . . . 0.18–0.25 0.75 . . . . . . . . .
Alloy 20 N08028 0.03 2.5 0.03 0.03 1 26.0–28 30.0–34 3.0–4


0.60–1.4


Alloy 20 N08029 0.02 2 0.025 0.015 0.6 26.0–28 30.0–34 4.0–5


0.6– 1.4





Heat Treatment Requirements

Grade UNS
Designation
Finished Heating Temperature Cooling/testing Requirements
TP304H S30409, S30415 Cold 1900 °F [1040 °C] See Spec
TP304H S30409, S30415 Hot 1900 °F [1040 °C] See Spec
TP310H S31009
1900 °F [1040 °C] See Spec
TP310H S31035
2160—2280 °F [1180—1250 °C] See Spec
TP316H S31609 Cold 1900 °F [1040 °C] See Spec
TP316H S31610 Hot 1900 °F [1040 °C] See Spec
TP321H S32109, S32615 Cold 2000 °F [1100 °C] See Spec
TP321H S32109, S32615 Hot 1925 °F [1050 °C] See Spec
TP321H S32654
2100 °F [1150 °C] See Spec
TP321H S33228
2050—2160 °F [1120—1180 °C] See Spec
TP321H S34565
2050—2140 °F [1120—1170 °C] See Spec
TP347H S34709 Cold 2000 °F [1100 °C] See Spec
TP347H S34709 Hot 1925 °F [1050 °C] See Spec
Alloy 20 N08020
1700—1850 °F [925—1010 °C] See Spec
Alloy 20 N08367
2025 °F [1110 °C] See Spec
Alloy 20 N08028
2000 °F [1100 °C] See Spec
Alloy 20 N08029
2000 °F [1100 °C] See Spec

Tensile Requirements

Grade UNS
Designation
Tensile Strength, Min  ksi [MPa] Yield strength, min ksi [MPa] other
TP304 S30400 75 [515] 30 [205]
TP304L S30403 70 [485] 25 [170]
TP304H S30409 75 [515] 30 [205]
TP304H S30415 87 [600] 42 [290]
TP310S S31008 75 [515] 30 [205]
TP310H S31009 75 [515] 30 [205]
TP310H S31035 95 [655] 45 [310]
TP316 S31600 75 [515] 30 [205]
TP316L S31603 70 [485] 25 [170]
TP316H S31609 75 [515] 30 [205]
TP316H S31635 75 [515] 30 [205]
TP317 S31700 75 [515] 30 [205]
TP317L S31703 75 [515] 30 [205]
TP317L S31725 75 [515] 30 [205]
TP317L S31726 80 [550] 35 [240]
TP317L S31727 80 [550] 36 [245]
TP317L S31730 70 [480] 25 [175]
TP317L S32053 93 [640] 43 [295]
TP321 S32100 75 [515] 30 [205] welded & seamless
TP321 S32100 75 [515] 30 [205] t = 0.375 in.
TP321 S32100 70 [480] 25 [170] t > 0.375 in.
TP321H S32109 75 [515] 30 [205] welded & seamless
TP321H S32109 75 [515] 30 [205] t = 0.375 in.
TP321H S32109 70 [480] 25 [170] t > 0.375 in.
TP321H S32615 80 [550] 32 [320]
TP321H S32654 109 [750] 62 [430]
TP321H S33228 73 [500] 27 [185]
TP321H S34565 115 [795] 60 [415]
TP347 S34700 75 [515] 30 [205]
TP347H S34709 75 [515] 30 [205]
Alloy 20 N08020 80 [550] 35 [240]
Alloy 20 N08028 73 [500] 31 [214]
Alloy 20 N08029 73 [500] 31 [214]
Alloy 20 N08367 100 [690] 45 [310] t = 0.187 in.
Alloy 20 N08367 95 [655] 45 [310] t > 0.187 in.

Elongation Requirements

Elongation in 2 in., min, % longitudinal Transverse Grain size
Longitudinal Transverse
35 25 35 25
35 25 35 25
35 25 35 25 7 or coarser
35 25 35 25
35 25 35 25
35 25 35 25 6 or coarser
35 25 35 25 7 or coarser
35 25 35 25
35 25 35 25
35 25 35 25 7 or coarser
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25 7 or coarser
35 25 35 25
35 25 35 25
25 25 3 or finer
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25
35 25 35 25 7 or coarser
35 25 35 25
40 40
40 40
30 30
30 30


ASTM A790 Duplex Stainless Steel Pipe-Saso Approved Falaj Irrigation Lines for Neom Smart City Solar Farms

ASTM A790 Duplex Stainless Steel Pipe-Saso Approved Falaj Irrigation Lines for Neom Smart City Solar Farms

ASTM A790 Duplex Stainless Steel Pipe-Saso Approved Falaj Irrigation Lines for Neom Smart City Solar Farms

ASTM A790 Duplex Stainless Steel Pipe-Saso Approved Falaj Irrigation Lines for Neom Smart City Solar Farms








Flattening Test

For material heat treated in a continuous furnace flattening tests shall be made on a sufficient number of pipes to constitute 5 % of the lot, but in no case less than 2 lengths of pipe.

Hydrostatic or Nondestructive Testing

Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test

Markings

Markings will adhere to prescribed specifications in A999/A999M and shall include the NPS or OD and schedule number or average wall thickness, heat number, and NH (when hydrotesting is not performed) and ET (when eddy-current testing is performed) or UT (when ultrasonic testing is performed). The marking shall also include the manufacturer’s private identifying mark, the marking requirement of section 12.3 on Hydrostatic or Nondestructive Electric Test, if applicable, and whether seamless (SML), welded (WLD), or heavily cold-worked (HCW). For Grades TP304H, TP316H, TP321H & TP347H, the marking shall also include the heat number and heat-treatment lot identification.






问答













Product Tags: Stainless Steel Round , ASTM A790 , manufactured in China

Send Inquiry to This Supplier

Message
0/5000

Want the best price? Post an RFQ now!
Gold Verified Supplier
2Yrs
Verified Business License
Main Markets
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location
Tianjin, China
