Help CenterPerkins 2206D-E13TA Engine PK3S0032, 309.5KW 2100 Rpm
Related Products
-
Perkins1104C-44TA(RJ51175R) Generator Set Engine 103KW, 1500 RpmNegotiableMOQ: 1 Piece -
Perkins1104A-44T Generator Set Engine 65.5KW, 1500 RpmNegotiableMOQ: 1 Piece
-
Caterpillar C2.2 / Perkins 404EA-22T Straight-4 Turbocharged Engine AssemblyUS$ 4620MOQ: 1 Piece
-
Perkins' New 404D-22 Engine Has a Total Success Rate of 35.7KWNegotiableMOQ: 1 Piece
-
Perkins 1104D-44T / Caterpillar C4.4 Engine, NL75007, 74.5KW / 2200 Rpm, With Heavy-duty PTO InterfaceNegotiableMOQ: 1 Unit
The Perkins 2206D - E13TA engine is a high - performance power unit, and the model PK3S0032 has a power output of 309.5KW at 2100 rpm. Here is a detailed introduction: - **Basic Specifications** - **Cylinder Configuration**: It adopts a 6 - cylinder vertical in - line structure, with a bore of 130mm and a stroke of 157mm. The displacement is 12.5L, which provides a strong power - generation foundation for the engine. - **Combustion System**: The engine uses a direct - injection combustion system, and the compression ratio is 17.3:1, which can make the fuel burn more fully and improve the engine's efficiency. - **Technical Features** - **Turbocharging and After - cooling**: This engine is equipped with a turbocharger and an air - to - air aftercooler. The turbocharger can increase the air intake, and the aftercooler can cool the intake air, improve the air density, and enhance the engine's power and economic performance. - **Electronic Control System**: It is equipped with a full - electronic control system, and all system functions are controlled by an electronic control module (ECM) installed on the engine. The flexible and configurable software features, combined with the SAE J1939 CAN bus, enable highly integrated machine operation. - **Fuel System**: The mechanical unit injector fuel system is electronically controlled, which can accurately control the fuel injection volume and injection timing, adapt to different working conditions, and improve fuel utilization efficiency. - **Performance Advantages** - **High - power Output**: With a power of 309.5KW at 2100 rpm, the engine can output strong power, which is very suitable for heavy - duty working conditions. It can provide sufficient power support for large - scale construction machinery, agricultural machinery and generator sets. - **Good Fuel Economy**: The Perkins 2206D - E13TA engine has optimized fuel consumption, which can be matched with the operating cycles of a variety of equipment. The 500 - hour oil change interval also helps to reduce maintenance costs and long - term operating costs. - **Reliability and Durability**: Perkins engines are famous for their reliability and durability. The 2206D - E13TA is manufactured with high - quality materials and advanced processes, which can operate stably in harsh environments, with a long service life and low failure rate. - **Emission Standards**: The engine is designed to meet the equivalent of Stage IIIA/Tier 3 emission standards, which not only has excellent power performance but also meets the environmental protection requirements, and is suitable for use in various regions. - **Application Fields**: This engine is an ideal choice for power generation equipment, and can provide main power or backup power for data centers, factories, etc. It can also be used as the power source of construction machinery and agricultural machinery, such as excavators, tractors, etc., to meet the power needs of different equipment.
Send Inquiry to This Supplier
