Help CenterPerkins1104A-44T Generator Set Engine 65.5KW, 1500 Rpm
Related Products
-
Caterpillar C2.2 / Perkins 404EA-22T Straight-4 Turbocharged Engine AssemblyUS$ 4620MOQ: 1 Piece -
Perkins' New 404D-22 Engine Has a Total Success Rate of 35.7KWNegotiableMOQ: 1 Piece
-
Perkins 1104D-44T / Caterpillar C4.4 Engine, NL75007, 74.5KW / 2200 Rpm, With Heavy-duty PTO InterfaceNegotiableMOQ: 1 Unit
-
Perkins 1706EA-E93TA Engine AssemblyNegotiableMOQ: 1 Piece
-
Perkins 2806D-E18TA Engine AssemblyNegotiableMOQ: 1 Piece
The Perkins 1104A - 44T is a high - performance generator set engine, boasting a power output of 65.5KW at 1500 rpm. It is part of Perkins' reliable 1100 series, which is well - recognized for its excellent performance in the power generation field. The following is a detailed introduction: - **Engine Structure and Basic Parameters** - **Cylinder Configuration**: It adopts a 4 - cylinder in - line layout, with a bore of 105mm and a stroke of 127mm, resulting in a displacement of 4.4L. This cylinder arrangement is simple in structure, convenient for maintenance, and can provide a good balance between power and compactness, suitable for a variety of generator set applications. - **Intake Mode**: The engine adopts a turbo - charging intake mode. The turbocharger uses the exhaust gas of the engine to drive, compresses more air into the cylinder, increases the air density, makes the fuel burn more fully, and improves the power and torque of the engine. - **Compression Ratio**: The compression ratio is 16.5:1. A higher compression ratio can make the mixture burn more intensely, release more energy, and improve the engine's thermal efficiency and power performance. The engine optimizes the combustion chamber design to give full play to the advantages of a high - compression ratio. - **Performance Advantages** - **Power Output**: With a power of 65.5KW at 1500 rpm, this engine can provide stable and reliable power for generator sets. It has a good torque performance, which enables it to handle sudden load changes well, and can meet the power needs of different working conditions, whether in industrial production, construction sites or commercial backup power supplies. - **Fuel Efficiency**: The 1104A - 44T is equipped with an advanced fuel system and combustion control technology. It adopts precise fuel injection technology, which can make the fuel and air fully mixed and burned in the combustion chamber, reducing fuel waste. Compared with similar engines, it can save about 10% of fuel, effectively reducing the operating cost. - **Reliability and Durability**: Perkins engines are renowned for their reliability, and the 1104A - 44T is no exception. Its cylinder block is made of high - strength materials, which has good pressure - resistance and anti - deformation ability, and can withstand the huge pressure and impact force generated during engine operation. The engine also has a reasonable lubrication system and cooling system, which can ensure the normal operation of the engine under long - term high - load conditions. - **Low Noise and Vibration**: Thanks to its excellent structural design and vibration - reduction measures, the 1104A - 44T engine has low noise and vibration levels. The in - line 4 - cylinder structure, combined with advanced balancing technology, minimizes vibrations, making it suitable for applications with noise restrictions, such as urban construction sites or commercial areas. - **Emission and Certification** - The 1104A series engines do not have emission certification, but the 1104 series, including the 1104C and 1104D models, are designed to meet EU Stage II/IIIA and US EPA Tier 2/Tier 3 equivalent emission standards. Although the 1104A - 44T may not have the same strict emission - reduction design as the latter, it still has relatively low emissions during operation due to its efficient combustion system, which is more environmentally friendly. - **Application Scenarios** - This engine is mainly used in the power generation field, and can be used as the main or backup power source of generator sets. In industrial plants, it can ensure the continuous operation of key equipment during power outages; in commercial buildings such as hospitals and data centers, it can provide reliable backup power to ensure the normal operation of essential services. In addition, it can also be used in off - grid or remote areas to provide self - sufficient power.
