TRICONEX 8110 High Density Mainframe Cabinet

Input Voltage: 24VDC

Power Consumption: 1.2W

Operating Temperature: -40℃ to +70℃

Operating Humidity: 0 to 95% RH (non-condensing)

Communication Method: Modbus RTU RS-485

Certification Standard: SIL 2 certification, compliant with IEC 61508 standard

High-Density Design: Can accommodate a large number of I/O modules, improving system integration, and supporting up to 192 digital I/O points and 96 analog I/O points.

Modular Structure: Facilitates system expansion and maintenance, and can be flexibly configured according to different needs.

Redundant Design: Adopts triple redundancy design to improve system reliability. Even if one module fails, it can ensure the safe operation of the system.

Multiple Communication Protocols: Supports various communication protocols such as MODBUS, PROFIBUS, and Ethernet, enabling interconnection with other devices.

Accommodating and Protecting Modules: Provides installation space for Triconex safety control modules and plays a physical protection role. It can accommodate multiple modules, including I/O modules and processor modules, ensuring that these modules can operate safely and reliably in industrial environments.

Expanding I/O Capacity: With high-density I/O characteristics, it supports up to 192 digital I/O points and 96 analog I/O points. It can also connect additional I/O modules through the RS-485 I/O expansion bus port, meeting the needs of various industrial automation systems for processing a large number of input and output signals.

Achieving Reliable Connection: Enables the connection between I/O modules and processors, allowing smooth data transmission and communication between modules, ensuring the normal operation of the overall system functions.

Providing System Power: Supplies power to each module in the chassis, ensuring that the modules can obtain stable power supply and maintain the normal operation of the system.

Ensuring System Safety: Certified by SIL 3, it can be used to build Safety Instrumented Systems (SIS). Combined with Triconex's Triple Modular Redundancy (TMR) structure, it performs 2-out-of-3 voting on inputs and outputs, improving the fault tolerance of the system. It can effectively monitor and control dangerous processes, quickly stop equipment in emergency situations, prevent the expansion of accidents, and protect personnel and equipment safety.

Supporting Multiple Communications: Supports multiple communication protocols such as MODBUS, PROFIBUS, and Ethernet, enabling interconnection with other devices or systems, realizing data sharing and collaborative control, and facilitating integration into larger-scale industrial automation control systems.

Facilitating System Maintenance: Adopts a modular structure, and the customized design facilitates maintenance and component replacement. When a module fails, it can be replaced quickly, reducing maintenance costs and system downtime.

Emergency Shutdown System (ESD)

Fire and Gas Detection System (FGS)

Burner Management System (BMS)

Reactor Protection System (RPS)

Redundant control of key equipment (such as compressors, pumps)

Safety interlocks for hazardous processes (such as chemical reactors)
