DS200DCFBG1BKC Power Panel

DS200DCFBG1BKC Power Panel photo-1
DS200DCFBG1BKC Power Panel photo-2
DS200DCFBG1BKC Power Panel photo-3
DS200DCFBG1BKC Power Panel photo-4
DS200DCFBG1BKC Power Panel photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.





  • Detailed Information on DS200DCFBG1BKC

  • Product Overview

  • The DS200DCFBG1BKC is a power supply board manufactured by General Electric (GE), part of the Mark V series. It primarily provides stable DC power to drives and supplies power to cabinet fans. It also monitors the fuse status of frequency converters, with feedback to users via two LED indicators and one neon indicator.
  • Technical Specifications

  • ParameterSpecification
    Input Voltage380–500V AC, three-phase
    Output Voltage24V DC
    Maximum Output Current60A
    Power Rating1440W
    Protection ClassIP20
    Operating Temperature Range-20°C to +70°C
    Dimensions230mm × 165mm × 45mm
    Weight2.5kg

GE DS200DCFBG1BKC



    • Circuit Composition

    • Control level power supply circuits (+5V, ±15V, and ±24V DC)

    • Motor excitation power supply circuits

    • Drive circuits for motor field SCR gate pulse generators

    • Circuits for monitoring signals such as armature current and voltage, motor excitation current, and AC line current

    • Interfaces & Configuration

    • Equipped with 12 jumpers and 7 DIP switches, configurable according to user requirements for selecting customer-specific options. Most jumper and DIP switch settings are factory-preset.

    • Status indicators: 2 LED indicators and 1 neon indicator for real-time feedback on power supply status and fuse conditions.

    • Protection Features

    • Integrated protection functions: overvoltage, overcurrent, undervoltage, and short-circuit protection.

    • 3 built-in protective fuses to shield against current interference, ensuring safe operation of equipment and the system.

    • Compatible Drives

    • DC2000, AC2000, FC2000, CB2000, and ME2000 series drives

    • Application Fields

    • Power Industry:Power plants, substations

    • Process Industries:Petrochemicals, metallurgy, papermaking

    • Infrastructure:Water treatment, sewage treatment facilities

    • HVAC Systems and other industrial automation scenarios requiring stable DC power supply
