SDCS-PIN-4 Power Interface Board ABB

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Guizhou Yuanmiao Automation Equipment Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

Operating temperature -40℃~+85℃

Humidity 5%~95% (non-condensing)

Many products are not on the shelves yet, please contact us for more models.

Product Overview: SDCS-PIN-4 is a power interface board from ABB, mainly used in the field of industrial automation. It can control the on/off of alternating current, detect and display power output, and provide stable power for related equipment. It can also be integrated into DCS800, with functions such as field current control, field heating, and dual field control.
Technical Parameters:

Power Supply Voltage: Usually 24VDC, and some data shows that the input voltage range is 110-240VAC.
Output Voltage Range: 24-28VDC.
Output Current: 4A.
Maximum Power: 80W.
Operating Temperature: -10℃ to +50℃ or -20℃ to +60℃.
Dimensions: Approximately 100mm x 70mm x 30mm or 120mm x 80mm x 35mm.
Weight: About 200g.
Protection Functions: Equipped with overload protection, overheating protection, short-circuit protection, overvoltage protection, etc.

Adopts PWM modulation technology, with a wide adjustable range of output voltage and high precision.
Features an open design, facilitating interface docking with other equipment.
Some models have encoder interfaces, supporting various types of encoders and feedback devices, and also include configurable digital I/O interfaces for various control and monitoring functions.

Application Fields: Suitable for fields such as industrial automation and power systems. It can realize high-precision control of key components such as machine tool spindles and feed axes, can be used to control conveying equipment such as conveyors and elevators, and can also be applied to speed control of wind turbine generators.
