Help CenterDuplex 2507 Stainless Steel Coil Tisco ASME SA240 Hot Rolled 0.8 1.0 1.2 1.5 2.0 mm No. 4 Surface High Stability Chemical Treatment 2507
Related Products
-
Duplex 2507 Stainless Steel Coil Tisco ASME SA240 Cold Rolled 0.5mm-3mm 2b Surface High Durability Energy Industry 2507 Stainless SteelUS$ 2500 - 3500MOQ: 1 Ton -
Duplex 2507 Stainless Steel Coil Tisco ASME SA240 Cold Rolled 0.5mm-3mm 2b Surface High Strength Aircraft 2507 Stainless Steel CoilUS$ 2500 - 3500MOQ: 1 Ton
-
Duplex 2507 Stainless Steel Coil Tisco ASME SA240 Cold Rolled 0.5mm-3mm 2b Surface High Crack Resistance Marine Engineering 2507US$ 2500 - 3500MOQ: 1 Ton
-
Duplex 2507 Stainless Steel Coil Tisco ASME SA240 Cold Rolled 0.5mm-3mm 2b Surface High Strength Aircraft 2507 Stainless Steel CoilUS$ 2500 - 3500MOQ: 1 Ton
-
Round Sea Worthy Package Stainless Steel 304 316 416US$ 1400MOQ: 1 Ton
| 2507/S32750 Stainless Steel Coil Manufacturing Process | Hot Rolled (HR) / Cold Rolled (CR) |
| 2507/S32750 Stainless Steel Coil Grades | 201 / 304 / 304L/ 2507/S32750 / 309S / 420 / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc. |
| UNS No. - UNS S2507/S32750, UNS S31008, UNS S31600, UNS S31603, UNS S31603, UNS S31600, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 | |
| EN No. 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539 | |
| 2507/S32750 Stainless Steel Coil Thickness | 0.6 MM TO 16 MM THICKNESS |
| 2507/S32750 Stainless Steel Coil Width | 1250 MM / 1500 MM / 2000 MM / 04 Feet / 05 Feet and Custom Cut Width as Per Requirement |
| 2507/S32750 Stainless Steel Coil Length | 2400 MM / 2420 MM / 6000 MM / 08 Feet / 10 Feet / Coil Cut and Custom Cut Length as Per Requirement |
| 2507/S32750 Stainless Steel Coil Surface Finish | 2B, 2D, BA, MATT, MATT PVC, No.4, No.5, SB, HR, No.8, Mirror, Hairline, Brush, Textured, Oil base wet Polished, Both sides Polished available. |
| 2507/S32750 Stainless Steel Coil Coating | PVC coating Normal / Laser, Film: 100 micrometer, Color: black/white. |
| 2507/S32750 Stainless Steel Coil Other Testing | NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, etc. |
| 2507/S32750 Stainless Steel CoilValue Added Services | Gas Cutting / CNC Plasma Cutting / Profiling / Rolling / Bending / Sheet Metal Fabrication / Drill / Punch / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| 2507/S32750 Stainless Steel Coil Packaging | Loose / Carrate / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps |
| 2507/S32750 Stainless Steel Coil Shipment & Transportation | By Road - Truck / Train Partial Load, Full Load, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| 2507/S32750 Stainless Steel Coil Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC |
| Manufacturer | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO,Arcelor Mittal, VDM,Nippon Metal, Qingshan,Delong. |
| Shipping Port | Shanghai/Ningbo port/Tianjin/Qindao |
Daxun is a premier 2507 Duplex Steel Coil supplier in China, offering a comprehensive range of coil thicknesses from 0.5mm to 3.16mm. Known for its cost-effectiveness compared to 904L or 6% molybdenum super austenitic stainless steel, the Alloy 2507 (UNS S32750) is a super duplex stainless steel with a robust composition of 25% chromium, 4% molybdenum, and 7% nickel. Designed for the most demanding applications, it excels in high strength and superior corrosion resistance, making it ideal for chemical processing, petrochemical, and seawater equipment. Its exceptional resistance to chloride stress corrosion cracking, high thermal conductivity, and low coefficient of thermal expansion further enhance its utility. The high concentrations of chromium, molybdenum, and nitrogen ensure formidable resistance to pitting, crevice corrosion, and general corrosion.
Daxun conducts an array of rigorous quality assurance tests to ensure material suitability for intended applications. These include flattening tests, pitting and resistance tests, mechanical tests, hardness tests, material positive identification, and expansion tests, among others.
Throughout the production process, we meticulously measure the diameter, thickness, and surface quality of our products. Standard delivery times are 7-15 days, with a potential extension to 20 days for special size products.
We strictly adhere to contract stipulations for delivery times.We welcome third-party agencies chosen by customers to inspect our factory.
We provide free samples to customers for testing purposes.
We support on-site or video factory inspections for customer assurance.
To place an order, please include the quantity, grade, type or category, API5L reference, thickness, width, length, and any specific requirements related to chemical composition, mechanical properties, heat treatment, additional testing, manufacturing process, surface coating, or end finish. Contact Daxun now for prompt email responses to your inquiries.
| Grade | Super Duplex 2507 |
| UNS Designation | S32750 |
| Carbon (C) Max. | 0.03 |
| Manganese (Mn) Max. | 1.2 |
| Phosphorous (P) Max. | 0.035 |
| *** (S) Max. | 0.02 |
| Silicon (Si) Max. | 0.8 |
| Chromium (Cr) | 24.0-26.0 |
| Nickel (Ni) | 6.0-8.0 |
| Molybdenum (Mo) | 3.0-5.0 |
| Nitrogen (N) | 0.24-0.32 |
| Iron (Fe) | Bal. |
| Copper (Cu) | 0.5 |
| Other Elements | - |
| Physical Properties of Super Duplex 2507 Alloys in the Annealed Condition at -20°F to +100°F | ||||||||||||||
| Tensile Strength | Yield Strength | |||||||||||||
| Alloy | UNS Designation | Spec. | psi | MPa | ksi | psi | MPa | ksi | Elongation in 2 in. (min.) % | Grain Size Req. | Max. Hardness | Modulus of Elasticity (x106 psi) | Mean Coefficient of Thermal Expansion (IN./IN./°F x 10-6) | Thermal Conductivity (BTU-in/ ft2-h-°F) |
| Super Duplex 2507 | S32950 | A789, A790 | 100,000 | 690 | 100 | 70,000 | 485 | 70 | 20 | - | 30.5 Rc | - | - | - |
| Super Duplex 2507 | S32750 | A789, A790 | 116,000 | 800 | 116 | 80,000 | 550 | 80 | 15 | - | 32 Rc | 27.5 | 7.2 | 98 |
| Density, lb/in3 | 0.28 |
| Modulus of Elasticity, psi | 29.0x 106 |
| Coefficient of Thermal Expansion, 68-212˚F, /˚F | 7.5 x 10-6 |
| Thermal Conductivity, Btu/ft hr ˚F | 8 |
| Specific Heat, Btu/lb ˚F | 0.12 |
| Electrical Resistivity, Microhm-in | 31.5 |
Duplex 2507 stainless steel is an exceptional super duplex grade, boasting a low carbon content (up to 0.03%) and a unique blend of chromium (~25%), nickel (~7%), and molybdenum (~4%). Specifically engineered for applications demanding unparalleled strength and superior resistance to corrosion, Duplex 2507 is ideal for chemical process equipment, the petrochemical sector, and seawater infrastructure. Its resilience against chloride-induced stress corrosion cracking is noteworthy. Thanks to its high levels of chromium, molybdenum, and nitrogen, it offers outstanding protection against pitting, crevice, and general corrosion, making it a top choice for challenging environments.
How Is Duplex 2507 Stainless Steel Made?The production of Duplex 2507 stainless steel mirrors that of other high-alloy steels. The process kicks off in an electric arc furnace, where scrap steel is melted and alloyed. Once molten, the steel is transferred to an AOD (argon oxygen decarburization) converter. Here, critical steps such as decarburization, sulfur refinement, and gas elimination are meticulously carried out to achieve the desired composition.
During the AOD process, nitrogen is typically incorporated. The steel then progresses to the ladle furnace for fine-tuning of its inclusions, ensuring optimal quality.
Post these initial stages, the molten steel is cast into either solitary ingots or continuously produced blooms. These solidified forms are then reheated and subjected to forging or rolling to attain the specified thickness. A solution annealing heat treatment followed by water quenching ensures a homogeneous internal structure, vital for the steel's integrity.
Fabrication of Duplex 2507 pipes can be executed via hot or cold forming techniques. Hot forming requires temperatures between 1024 °C and 1232 °C, followed by solution annealing at 1052-1125 °C and rapid water quenching. Cold forming methods, such as bending, deep drawing, extruding, and pressing, necessitate subsequent heat treatment, including solution annealing and quenching, to preserve the material's properties.
Duplex 2507 stainless steel stands out as a super duplex category within the duplex family. Duplex stainless steels feature a microstructure combining ferrite and austenite in nearly equal parts, harnessing the best traits of both phases. This results in high corrosion resistance coupled with strong mechanical strength. Despite the shared attributes, different duplex grades offer varying corrosion resistance levels, contingent on their specific alloy compositions. While duplex steels exhibit excellent resistance to localized corrosion such as pitting, crevice corrosion, and stress corrosion cracking, their exact performance hinges on the grade and PREN (Pitting Resistance Equivalent Number). Super duplex stainless steels, including Duplex 2507, boast a PREN range of 38 to 45, signifying their superior corrosion resistance.
Some common applications of Duplex 2507 stainless steel include:
Desalination.
Oil and gas industry equipment, including offshore platforms, pipelines, and well casings.
Chemical processing equipment, especially for handling corrosive chemicals.
Pulp and paper industry, particularly bleaching process equipment.
Petrochemical industry applications, including PVC strippers.
Water desalination plants.
Power industry equipment, such as flue gas desulfurization (FGD) systems.
Marine components, including ship propellers and shafts.
Pollution control equipment such as scrubbers.
Fittings are vital components for seamlessly connecting and regulating fluid flow within pipelines and systems. These essential elements include elbows, tees, stub-ends, returns, caps, crosses, reducers, and pipe nipples, among others.
The advantages of using Duplex 2507 stainless steel include:
Duplex 2507 stainless steel boasts exceptional resistance to pitting corrosion, with a PREN of up to 43. This surpasses stainless steel grades such as 254SMO. Additionally, Duplex 2507 offers high resistance to various other types of corrosion, including Stress Corrosion Cracking (SCC), crevice corrosion, and general corrosion. These combined properties render Duplex 2507 a versatile and reliable choice for numerous applications in challenging environments.
Duplex 2507 provides double the yield strength compared to 300 series stainless steel. This increased strength allows for the use of thinner steel sections, reducing material costs for equipment operating under similar load conditions.
Duplex 2507 boasts twice the yield and tensile strength of standard stainless steel, significantly enhancing wear resistance.
ASTM/ASME ...... A240 - UNS S32750
EURONORM ...... 1.4410 - X2 Cr Ni MoN 25.7.4
AFNOR ............ Z3 CN 25.06 Az
Q1: What products can you offer?
A: We offer a comprehensive range of steel types, including 310S, 316L, 304, 304L, 201, 904L, 316H, 316, 316L 300 series400 series, and duplex stainless steels like 2205, 2304, 2101, 2507, etc., as well as high-nickel alloys such as 904L, 800H, and 600H.
Q2. Can you produce the products according to my own drawings?
Yes, we can manufacture products according to your drawings, ensuring utmost satisfaction.
Q3. How does your factory do regarding quality control?
Quality is our top priority. We consistently emphasize stringent quality control from start to finish.
Q4. Can I request to change the form of packaging and transportation?
Absolutely! We can modify the packaging and transportation methods as per your request,
though you will need to cover any additional costs and price differences incurred during this period.
Q5. How does your factory do regarding quality control?
Quality is our top priority. We consistently emphasize stringent quality control from start to finish.
Q6. How long is the delivery time?
A: Delivery typically takes 7 to 20 working days after payment confirmation.
For urgent orders, we will expedite production to meet your deadlines.
Q7. What is your Payment?
A: 100% T/T in advance, Western Union (For Small Orders)
B: 30% T/T upfront, with the remaining 70% due before shipment
C: 100% Irrevocable LC at sight (For Large Orders)
Q8: Can you make DDQ (Deep Drawing Quality)?
A: Yes, we can. Our materials are suitable for applications such as stainless steel pots, sinks, and bowls. Just inform us of your specific needs, and we will tailor the mechanical properties accordingly.
Q9: How to get a sample?
A: We are pleased to offer FREE samples for your evaluation and testing. Should you need a small piece, we may cover the courier cost, depending on the specifics.
Q10: To which countries have your products been exported?
A: To date, we have proudly exported our premium stainless steel materials to a diverse range of countries, including Vietnam, Thailand, Turkey, Russia, Morocco, South Korea, India, Pakistan, UAE, Ukraine, and many more.
